Old 03-13-2006, 09:14 PM   #1
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
Weight Reduction Reference, Survey & FAQ

Seven-of-nine had a great idea - make a single point thread for weight reduction information. So here it is.

Heres the deal - If you have removed something from the car and weighed the component removed on a reliable scale please list the component and weight in reply to this thread in the format below. We have done this for the Turbo FAQ in the forced induction forum and it worked great!

Item removed - weight in pounds

Example: Spare Tire - 10 lbs. (this is not accurate - just an example).
Example: Stock GTS wheel & tire assembly - 45 lbs. (again just an example)

If you REPLACED the component with a lighter composite part please list the brand and weight on the new component as well.

Example: Fiber Images Rear Hatch from Smaay - 10 lbs (again just an example)

You can also post your current vehicle weight and the fuel level in car (if you were in the car please subtract your weight before posting) if you have been to the scales along with a list of weight reduction mods. Please use the format below:

Weight - Year and model - fuel level - transmission type - member name
Example:
2001 lbs. - 2000 GTS - 1/2 tank - Manual - 00SilverGTS6speed

Also feel free to use this thread for any questions or suggestions about weight reduction.

I will try to keep up with all the items posted and list them in this top post.


Thanks for your cooperation!

Oh - if someone else feels strongly that they would like to maintain this speak up now and you can just copy this thread and start a new one with the same stuff - I don't feel the strong need to maintain it but I will if no-one else wants to.



************************************************** ********
************************************************** ********
Weight Reduction Table

===Part 1. STOCK INTERIOR===

Item Removed *** Weight *** Board member that provided data
----------------------------------------------------------------[/b]
Cargo cover*** ** *** ** *** ****6 lbs **Speed4Theneed
Cargo cover*** ** *** ** *** ****7 lbs **goose42
Carpet***********************15 lbs **Illusive
Hatchback with struts (no glass) ****33lbs **Monster Hui
Headliner**********************2 lbs **Speed4Theneed
Jack *************************5 lbs **Jlitman
Jack *************************4 lbs **goose42
Moonroof (Plastic) ***************11lbs **Monster Hui
Moonroof tracks with motor ********14lbs **Monster Hui
Panel (door panels--both)* * * * * *13 lbs **Speed4TheNeed
Panel (rear trunk panels incl. tray * *15 lbs **Jlitman
Radio/CD player **************** 4 lbs **Speed4TheNeed
Seat (rear cushion) **************7 lbs **Jlitman
Seat (rear cushion) **************7 lbs **goose42
Seat (rear seats) ***************22 lbs **Jlitman
Seat (rear seats) ***************22 lbs **goose42
Seat (front cloth, no airbag)******* 32 lbs **Speed4TheNeed
Seat (front leather, no airbag)******35 lbs **Speed4Theneed
Seat (front)******************* 37 lbs **goose42
Seatbelts (all 4, minus females)**** 9.5 lbs **Speed4TheNeed
side pass. airbag w/ cover panel ****7.5lbs **Monster Hui
Spare tire (donut) ************** 24 lbs **Jlitman
Spare tire (full size) ***** * * * * * 40 lbs **goose42
Sound Deadening Material *********18 lbs **Shizuma
Steering wheel (w/airbag)***** * ***9 lbs **Speed4Theneed
Steering wheel ******************6 lbs **goose42
sun visors (pair) *****************1 lbs **Monster Hui


===Part 2. STOCK EXTERIOR===

Item Removed *** Weight *** Board member that provided data
----------------------------------------------------------------

Front Brakes(GTS) (Disc, caliper and pads - one side) *** 27 lbs ** Many
Control arms (rear upper) (pair) **** 5.5 lbs **Monster Hui
Fender (each) * ** * * * * ** ** * * 5 lbs **Speed4Theneed
Hood (with scoop) **** **********23 lbs **Speed4Theneed
Mirros (both w/motor) ** ***** * * * 5 lbs **Speed4Theneed
Spoiler (regular)********* ** * * * *5 lbs **goose42
Springs (front - each) ************ 4 lbs ** detaB
Springs (rear - each) ***** *** **** 3 lbs ** deltaB
sway bar (rear) **************** 6.5 lbs ** Many
sway bar (front) *************** 9.5 lbs ** Many
Tire (each -- 205/50/16) * * * * * **21 lbs **Jlitman
Wheel (16"--each)***************18 lbs **Jlitman
Wheel (all four 16" w/tires)********160 lbs **goose42


===Part 3. Stock Mechanical, Performance, Etc..===

Item Removed *** Weight *** Board member that provided data
----------------------------------------------------------------

A/C compressor & clutch ***********12 lbs **Speed4TheNeed
A/C condenser (no tubing)* ******** *5 lbs **Speed4TheNeed
A/C system (minus evaporator)*******21 lbs **goose42
Alternator **********************11 lbs **Speed4Theneed
Battery*** *** *** ** *** ** *****33 lbs **goose42
Clutch Pressure Plate (Clutch cover) ** 8.7 lbs ** deltaB
Crankshaft (1ZZ)****** **** ******20 lbs **Speed4Theneed
Crankshaft (2ZZ)******* ** * * ****27 lbs **Speed4TheNeed
Crank Pulley (2ZZ) *************** 3.5 lbs ** Monster Hui
Alt pully (2ZZ) ****************8oz (220g) **Seven of Nine
Water pump pulley (2ZZ)*** 8.9oz (3.25grams) **Seven of Nine
Cruise control******************** 6 lbs **Jlitman
Exhaust (GT-S axleback)***** ******27 lbs **Jlitman
Exhaust (GT-S axleback) ********* 27.5 lbs **Turbo Magazine (Speed4Theneed)
Exhaust************************25 lbs **goose42
Flywheel - GT-S *************** 13.38 lbs**Speed4TheNeed & DeltaB
Header (1ZZ w/heatshields)***** * ***9 lbs **Speed4TheNeed
Header************************* 9 lbs **goose42
Intake manifold (2zz)***** ******** 11 lbs **Jlitman
Lug Nuts (All 20) ************2 lbs 15.7oz **deltaB
Radiator***************** *******4 lbs **Speed4TheNeed
Radiator fans ******************** 9 lbs **Monster Hui
Springs****** **** * ****** *****16 lbs **goose42
Transmission - C60 6SPD (GTS) ******76 lbs **E13
Windshield wiper (rear w/motor)*******3 lbs **goose42



************************************************** ********
************************************************** ********
[b]Replacement Components Table

1. Performance mods


------A. Intakes, Air filters

Intakes:
AEM CAI w/filter************** *************2 lbs **Speed4TheNeed
Injen CAI w/filter*** ** ** * ** * * **********3.5 lbs **Speed4TheNeed
Blitz SUS power type LM intake (short ram intake)**2.5 lbs **Monster Hui

------B. Exhausts, Cats

Exhausts:
5Zigen Fireball**** *********** 26.5 lbs **Turbo Magazine (Speed4TheNeed)
A'PEXi N1********** **** ** **23.5 lbs **Turbo Magazine (Speed4Theneed)
Blitz*************************21 lbs **Turbo Magazine (Speed4TheNeed)
GReddy Evo 1*************** *35.5 lbs **Turbo Magazine (Speed4TheNeed)
GReddy Evo 2******************35 lbs **Jlitman
HKS Hi-Power****** ** *********28 lbs **Turbo Magazine (Speed4Theneed)
Magnaflow********* ***********20 lbs **goose42
Rod Millen*********************28 lbs **Turbo Magazine (Speed4TheNeed)
Tanabe Racing Medallion**********29 lbs **Turbo Magazine (Speed4TheNeed)
TRD Kazuma*******************20 lbs **Speed4Theneed
TRD (normal)****************** 25 lbs **Turbo Magazine (Speed4TheNeed)
Veilside Tear Drop (titanium)********8 lbs **Turbo Magazine (Speed4TheNeed)
Fujitsubo Power Getter Exhaust ***19.6 lbs. ** Rey_Vibora
Fujitsubo Legalis R Exhaust ****** 16.2 lbs.** Rey_Vibora
C-ONE Titanium Exhaust ******** 10.58 lbs.** Rey_Vibora
Trial 60mm bazooka exhaust ******* 8.0 lbs ** Monster Hui
Trial 80mm bazooka exhaust ******* 7.5 lbs ** Monster Hui


------C. Headers
DC Sports ceramic (2ZZ)**********6.5 lbs **Speed4TheNeed
DC Sports*** * * ** ** *** *******5 lbs **goose42
TRD race long tube (2ZZ)*** ** **** 8 lbs **Speed4TheNeed
------D. Pulleys

------E. Engine Internals, Engine Hardware

Valves:
Supertech 2ZZ (all 16)*********** *1 lbs **Speed4TheNeed

Valve Springs:
Eibach 2ZZ (all 16)**************0.5 lbs **Speed4Theneed

Rods:
Crower MWR 2ZZ stroker (all four)* * *9 lbs **Speed4TheNeed

Pistons:
Wiseco 2ZZ 12.5:1 (all four)*******2.5 lbs **Speed4TheNeed

Sleeves:
Darton 2ZZ (all four)**************4 lbs **Speed4TheNeed

------F. Turbochargers, Superchargers, Nitrous (combined)

Superchargers:
GReddy (2ZZ complete kit)****************36 lbs **Jlitman

------G. Other
Radiators:
Koyo Racing****************************9 lbs **Speed4TheNeed
Sard Racing sports radiator ****************13 lbs **Monster Hui


Oil Coolers:
TRD 2ZZ******************** ** ******1.5 lbs **Speed4TheNeed

Oil Pans:
Moroso 1ZZ/2ZZ****************** *****10 lbs **Speed4TheNeed

Pulleys:
AEM alternator pulley ******************** 1 lb **Speed4TheNeed
C-One aluminum crankpully *************** 1.5 lbs **Monster Hui
Unorthodox Racing alt pulley *******4oz's (100grams) **Seven of Nine
Unorthodox Racing water pump pulley** 7oz's (200grams)**Seven f Nine

2. Drivetrain


------A. Flywheels
AASCO (aluminum)********************8.0 lbs.
Blitz Active Clutch (chromoly)* **** **** 10.5 lbs.
C-One (chromoly)******************* 9.92 lbs.
C-ONE Light Weight Fly-Wheel "Type:R" ***8.8 lbs.
Fidanza (aluminum)GT-S****************7.5 lbs.
Fidanza (aluminum) GT********* **** ***8.5 lbs
Gripforce (chromoly)***************** 11.0 lbs.
JUN (chromoly)********************** 9.7 lbs.
Mueller (aluminum)******** *********** 8.0 lbs.
MWR (forged chromoly) GT-S* ** * ***** 10.5 lbs.
MWR (forged chromoly) GT*************10.2 lbs.
RPS Cyn-R-G Segmented (aluminum) * * * * 9.5 lbs.
Toda (chromoly)******************* 10.36 lbs.
TOM's (chromoly)********************8.03 lbs.
TRD Japan Flywheel (chromoly)********** 9.6 lbs.
Unorthodox (aluminum)*****************8.0 lbs.


------B. Clutches
RPS Max (pressure plate)***************7.9 lbs

------C. LSDs, Shift Kits, Gears (combined)


3. Suspension, Brakes


------A. Struts, Shocks, Springs, Coilovers (combined)

Springs:
Hotchkis (all four)************ *** ***** 24 lbs **goose42
TRD (all four)*************************20 lbs **Speed4TheNeed

Shocks:
TRD (all four)*************************24 lbs **Speed4Theneed


------B. Sway Bars, Misc. Suspension (combined)

Sway Bars:
Hotchkis Street (both)*******************9 lbs **Speed4TheNeed
TRD (both)********* *****************17 lbs **Speed4TheNeed

Camber links:
Hotchkis rear (both)*********** *** ***** 5 lbs **Speed4TheNeed

Endlinks:
Hotchkis (all four)********************** 4 lbs **Speed4TheNeed


------C. Chassis Braces

Chassis Braces:
APR front strut bar********************* 4 lbs **Jlitman
C-One trunk bar*********************** 3 lbs **Jlitman
TRD rear strut bar*** **** ** *** ********5 lbs **Jlitman


------D. Brake Pads, Rotors, Calipers, BBKs (combined)

Front Brakes:
TRD / Stoptech Disc, caliper and pads -****** 25 lbs *** Many
4. Exterior Appearance


------A. Bodykit Components (bumpers, sides, lips)

------B. Hoods, Spoilers, Scoops (combined)

------B. Wings
Trial/Voltex GT Wing **********************8 lbs **Monster Hui
Molly wing *****************************8.5lbs **Many

Hoods:
C-One ver.2 carbon fiber******************9 lbs **KamiSpeed (Speed4TheNeed)
Varis Cooling carbon fiber* ** * *** *********14.3 lbs **KamiSpeed (Speed4Theneed)
Veilside FFGT carbon fiber hood *************15 lbs ** PNOY (Speed4TheNeed)


Hatches:
ViS OEM style*********************10 lbs **Speed4TheNeed

------C. Engine compartment, Other Miscellaneous (combined)

Batteries:
Braille Race************* **** * * 11.5 lbs **Speed4TheNeed
Braille All Season****** ****** ** ***15 lbs **Speed4TheNeed
Hawker Odyssey*******************15 lbs **goose42]

------D. Wheel & Tire, Accessories

Wheels:
enkei rpf1 18-8 40m offset(each) *****17.8 pounds
Rota Subzero 15" (each)****** *****12.8 lbs **Jlitman
Rota Slipstreams 15x6.5 (each) ******11.25 lbs
Volk CE-28n 16 X 7 (each)**********10.5 lbs **Speed4TheNeed
Volk CE28N 17x7.5 (each) **********13.5 lbs **Monster Hui
SSR Competition 16x6.5 (each) ******11.5 lbs **Monster Hui
TE37's 16x7 ******************** 11.5 lbs **DYI01
C-ONE SA-70 17x8" ***************18 lbs. ** Rey_Vibora
www.wheelweights.net/ (you can choose by alphabetical order, by size, or by weight)
www.wheelweights.com (manufacturer specs...but I'd say at least half of the weight specs aren't filled in).


Tires:
Hankook Ventus R-S2 Z212 195/50ZR15W (ea) ** 18.9lbs **deltaB
Hankook Ventus R-S2 Z212 205/50ZR15W (ea) ** 20.4lbs **deltaB
Toyo T1-S 195/55/15 (each)****************16.5 lbs **Jlitman
Yokohama A048 M comp. 215/45 17 (each) *****22.5 lbs **Monster Hui
Yokohama A032R 225/45 R17 (each) *********** 23 lbs** Many
Yokohama A032 H comp. 205/55 16 (each) *****22.5 lbs **Monster Hui
Yokohama A032 H comp. 225/50 16 (each) ******25 lbs **Monster Hui
Kumho V710 225/50 16 (each) **************23.5 lbs **Monster Hui
Pirelli PZero Nero M&S 205/50ZR16 (each) ***** 20.5 lbs **Punkers7465

Wheel/Tire Sets:
Icon 17"/Kumho (full set) ***********152 lbs **goose42
Dunlop SP8000 (each) ********** *16.25 lbs ** deltaB


Lug nuts:
Rays lightweight (all 20)* *** * ** *****1 lbs **Speed4Theneed
Mutegi closed end (All 20) ********* 1lb 7.3oz **deltaB

5. Interior Appearance


------A. Seats, Seat accessories, Harnesses (combined)

Seats:
APC F1*********************** **** 35 lbs **Speed4TheNeed
Momo RS GT********************** 16.2 lbs **Speed4TheNeed
Momo RS2 GT**********************21.2 lbs **Speed4TheNeed
Momo Strt Rcr GT********* ** * *** * 25.4 lbs **Speed4TheNeed
Recaro Profi SPA**********************8 lbs **Speed4TheNeed
Recaro SP-GTII ******************** 11.5lbs **Monster Hui
Recaro SR-III (each) ***************** 30 lbs **Preludekid
Recaro sliders/bracket (for celica) ******* 6.0lbs **Monster Hui
Sparco Torino ********************* 41.0lbs **Monster Hui
Sparco Circuit***********************25 lbs **Speed4TheNeed
Sparco Corsa*********************** 22 lbs **Speed4TheNeed
Sparco Evo*********************** 18.5 lbs **Speed4TheNeed
Sparco Evo (carbon fiber)*************12.5 lbs **Speed4TheNeed
Sparco Evo 2******************* ** 18.5 lbs **Speed4TheNeed
Sparco Evo 3******************* ****22 lbs **Speed4TheNeed
Sparco Fighter********************** 20 lbs **Speed4TheNeed
Sparco Milano ********************** 44 lbs **Speed4TheNeed
Sparco Milano 2********************* 44 lbs **Speed4TheNeed
Sparco Milano Prestige**************** 48 lbs **Speed4TheNeed
Sparco Monza***********************40 lbs **Speed4TheNeed
Sparco Pro************************21.5 lbs **Speed4TheNeed
Sparco Pro (carbon fiber)***************13 lbs **Speed4TheNeed
Sparco S-Light********************** 25 lbs **Speed4TheNeed
Sparco Sienna***********************30 lbs **Speed4TheNeed
Tenzo R********** * ***** ** * ** ***26 lbs **goose42

Bases, Sliders, Brackets, etc:
Recaro bases, sliders, side mounts (both)***35 lbs **Speed4TheNeed

------B. Steering Wheels & Hubs

Steering Wheels:
OMP*******************************4 lbs **goose42


------C. Shift knobs, Pedal sets, Other Miscellaneous (combined)[/QUOTE]





************************************************** ********
************************************************** ********
Celica Weigh in

Weight *** Year & Model *** fuel level *** Transmission *** Screenname
----------------------------------------------------------------

1930 lb *** 2002 GTS *** almost empty tank *** Manual *** superman1240
2380 lb *** 2002 GTS *** empty tank ******** Manual *** goose42
2260 lb *** 2001 GT **** 3 Bars on gauge **** Manual *** Rytek
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com

Last edited by Boosted2.0; 12-22-2006 at 12:24 PM..
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Sponsored Links
Advertisement

Old 03-14-2006, 01:39 AM   #2
jlitman

Join Date: Oct 2004
Location: Under a red sun
Posts: 11,169
iTrader: (42)
**Removed**
Factory exhaust = 27 lbs
Back seat cushion = 7 lbs
Back seats = 22 lbs
Trunk panels (including tray) = 15 lbs
Spare tire = 24 lbs
Jack = 5 lbs
Cruise control = 6 lbs
Stock intake manifold = 11 lbs
OEM 16" wheel = 18 lbs each
OEM Yokohama tires 205/50/16 = 21 lbs each

**Added or replaced**
EVO 2 exhaust = 35 lbs
TRD rear strut bar = 5 lbs
APR front strut bar = 4 lbs
C-One trunk bar = 3 lbs
GReddy supercharger and manifold = 36 lbs
Rota Subzero 15" wheels = 12.8 lbs each
Toyo T1-S tires 195/55/15 = 16.5 lbs each
__________________

Last edited by jlitman; 03-14-2006 at 01:50 AM..
jlitman is offline   View this Members' Photo Gallery Reply With Quote
Old 03-14-2006, 03:57 AM   #3
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
REPLACEMENT sway bars:

TRD front sway bar: 9 lbs
TRD rear sway bar: 8 lbs
TRD TOTAL: 17 lbs

Hotchkis front sway bar: 5 lbs
Hotchkis rear sway bar: 4 lbs
Hotchkis TOTAL: 9 lbs

REPLACEMENT--Recaro Profi SPA seat (without sliders)
8 lbs

REPLACEMENT -- TRD springs (all four)
20 lbs

I'll have stock hood, stock fender, stock A/C compressor, clutch, and condenser, alternator, battery, front seats, recaro sliders w/side mount brackets, and a bunch of other stuff later on today. It's all uninstalled, just need to put it on a scale.
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote

Old 03-14-2006, 07:06 AM   #4
jlitman

Join Date: Oct 2004
Location: Under a red sun
Posts: 11,169
iTrader: (42)
Quote:
Originally Posted by Speed4TheNeed
REPLACEMENT sway bars:

TRD front sway bar: 9 lbs
TRD rear sway bar: 8 lbs
TRD TOTAL: 17 lbs

Hotchkis front sway bar: 5 lbs
Hotchkis rear sway bar: 4 lbs
Hotchkis TOTAL: 9 lbs

REPLACEMENT--Recaro Profi SPA seat (without sliders)
8 lbs

REPLACEMENT -- TRD springs (all four)
20 lbs

I'll have stock hood, stock fender, stock A/C compressor, clutch, and condenser, alternator, battery, front seats, recaro sliders w/side mount brackets, and a bunch of other stuff later on today. It's all uninstalled, just need to put it on a scale.
Do you happen to know what the OEM sways and springs weigh for comparison?
__________________
jlitman is offline   View this Members' Photo Gallery Reply With Quote
Old 03-14-2006, 03:26 PM   #5
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
Not yet. Waiting to get the engine running before the stock suspension components come out. If someone doesn't chime in before then I'll know when my car is running again.
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-14-2006, 04:53 PM   #6
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
Well I hope somebody loves me after today:

STOCK PARTS:

A/C compressor & clutch:.............12 lbs
A/C condenser (no tubing):.......5 lbs
Fender.......................................5 lbs (each)
Headliner....................................2 lbs
Steering wheel WITH airbag...........9 lbs
Radiator.....................................4 lbs
Cloth seats (no airbag).................32 lbs (each)
Leather seats (no airbag)..............35 lbs (each)
Radio..........................................4 lbs
Alternator...................................11 lbs
Mirrors (with motor)........................5 lbs (both)
Seatbelts....................................9.5 lbs (all four--female receptors NOT included)
1ZZ header w/heatshields................9 lbs
hatch cover...................................6 lbs
hood w/scoop................................23 lbs
2ZZ crankshaft...............................27 lbs
1ZZ crankshaft...............................20 lbs



AFTERMARKET PARTS

ViS carbon fiber hatch.............10 lbs (without window)
Koyo Racing radiator.................9 lbs
AEM CAI w/filter.......................2 lbs
Injen CAI w/filter.....................3.5 lbs
TRD shocks.............................24 lbs (all four)
TRD oil cooler..........................1.5 lbs
TRD Kazuma exhaust.................20 lbs (includes both sections + hanger rail)
Hotchkis rear camber links...........5 lbs (both)
Hotchkis end links......................4 lbs (all four)
2ZZ DC Sports ceramic header....6.5 lbs
Recaro seat brackets.................35 lbs (BOTH--includes sliders & steel side mount brackets)
Rays lug nuts............................1 lbs (all 20, key not included)
Moroso oil pan...........................10 lbs
2ZZ Eibach valve springs.............0.5 lbs (all 16)
2ZZ Supertech valves..................1 lb (all 16)
2ZZ MWR stroker Crower rods........9 lbs (all 4)
2ZZ Wiseco 12.5:1 pistons...........2.5 lbs (all 4, includes rings & pins)
2ZZ Darton dry sleeves.................4 lbs (all 4)
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set

Last edited by Speed4TheNeed; 03-14-2006 at 06:35 PM..
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-14-2006, 05:00 PM   #7
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
Volk CE-28n 16X7 wheels (10 spoke pattern)......10.5 lbs each

Dash, center console (with armrest), both door sills, both kick panels, glove box, underdash panel.....30 lbs (Sorry I couldn't weigh these independently of each other).

Both door panels...13 lbs (everything still attached that naturally comes out with it).
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set

Last edited by Speed4TheNeed; 03-14-2006 at 06:35 PM..
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-14-2006, 08:16 PM   #8
808CeLiCa

Join Date: Nov 2004
Location: maui, hawaii
Posts: 135
iTrader: (0)
i took out both door panels, spare tire, passenger seat, rear seats(both bottom and the lean on), toyota jack...dont really remember exact weight but i think it was about 100 pounds..unless my scale is broken...sorry guys i dont remember what pounds was for what i took off.
808CeLiCa is offline   Reply With Quote
Old 03-14-2006, 08:40 PM   #9
goose42

Join Date: Aug 2004
Location: Calgary, Alberta
Posts: 33
iTrader: (0)
I hope this shows up properly. I cut and pasted from a spreadsheet I made.
My last measured weight on a truck scale where a friend works was 2380 lb on an empty tank. This doesn't account for a couple of the latest mods. The table below isn't quite complete either.


Original Piece (lb) Replacement (lb)

Exhaust 25 Magnaflow 20
Ex Header 9 DC Sports 5 (no heat shield)
Wheels (16") /Tires 160 Icon (17")/Kuhmo 152
Rear Spoiler 5 *
Rear Wiper / Motor 3 *
Spare Tire (full size) 40 *
Jack 4 *
Passenger Seat 37 Tenzo R 26
(incl oem sliders)
Driver's Seat 37 Tenzo R 26
(incl oem sliders)
Rear Seat Cushion 7 *
Rear Seat Backs 22 *
Steering Wheel 6 OMP 4
Rear Cargo Cover 7 *
Battery 33 Hawker Odyssey 15
Springs 16 Hotchkis 24
Air Conditioning 21 *
(compressor/condenser/tubing)
goose42 is offline   Reply With Quote
Old 03-14-2006, 09:36 PM   #10
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
Updated - thanks for all the great infor guys! Keep it coming!
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-15-2006, 04:10 AM   #11
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
These are compliments of Turbo & High-Tech Performance Magazine:

GT-S Factory exhaust...........................27.5 lbs
GT-S 5Zigen Fireball exhaust..................26.5 lbs
GT-S A'PEXi N1 exhaust.........................23.5 lbs
GT-S Blitz exhaust................................21.0 lbs
GT-S GReddy Evo 1 exhaust...................35.5 lbs
GT-S Tanabe Racing Medallion exhaust.....29.0 lbs
GT-S Rod Millen exhaust........................28.0 lbs
GT-S TRD exhaust................................25.0 lbs
GT-S Veilside Teardrop titanium exhaust.....8.0 lbs
GT-S HKS Hi-Power exhaust....................28.0 lbs
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-15-2006, 04:23 AM   #12
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
Compliments of KamiSpeed:

Varis carbon fiber cooling hood........14.3 lbs
C-One ver.2 carbon fiber hood........~9.0 lbs
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-15-2006, 09:11 AM   #13
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
Updated again.
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-15-2006, 02:55 PM   #14
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
If we can get some bodykit weights that would be great..including the stock bumpers/sides and the TRD action package bodykit.
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-15-2006, 03:03 PM   #15
Shizuma
Professional Carsmith

Join Date: Mar 2005
Location: Houston, TX
Posts: 6,311
iTrader: (42)
Send a message via AIM to Shizuma
I've still got all the sound deadening material I've scraped out (front/rear seats and trunk) so far in a bag in my garage, once I'm finished I'll weigh it...itz obviously something that can vary from car to car but you should be able to get a pretty good idea from it
__________________
Shizuma is offline   View this Members' Photo Gallery Reply With Quote
Old 03-15-2006, 03:10 PM   #16
SickCelica696

Join Date: Dec 2004
Location: Annapolis MD
Posts: 8,225
iTrader: (20)
Send a message via AIM to SickCelica696
Quote:
Originally Posted by Speed4TheNeed
GT-S Veilside Teardrop titanium exhaust.....8.0 lbs
__________________

MS3 GT: Lost count of mods
2000 GT-S for sale, $5000, PM me.
SickCelica696 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-15-2006, 04:01 PM   #17
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
Boosted2.0, This is the same STOCK list you have posted above, just categorized and in alphabetical order (for ease of use). You were probably going to do this anyway once we got enough entries, just figured I'd get a head start. I'll try and do the aftermarket parts list later, but I don't have the time right now.

I left duplicate entries in place for the time being. If in the future you want to use a single listing it's your call.

Part 1 = Stock Interior
Part 2 = Stock Exterior
Part 3 = Stock Mechanical, Performance, etc.

=========STOCK PARTS=========

===Part 1. STOCK INTERIOR===

Cargo cover*** ** *** ** *** ****6 lbs **Speed4Theneed
Cargo cover*** ** *** ** *** ****7 lbs **goose42
Carpet***********************15 lbs **Illusive
Headliner**********************2 lbs **Speed4Theneed
Jack *************************5 lbs **Jlitman
Jack *************************4 lbs **goose42
Panel (door panels--both)* * * * * *13 lbs **Speed4TheNeed
Panel (rear trunk panels incl. tray * *15 lbs **Jlitman
Radio/CD player **************** 4 lbs **Speed4TheNeed
Seat (rear cushion) **************7 lbs **Jlitman
Seat (rear cushion) **************7 lbs **goose42
Seat (rear seats) ***************22 lbs **Jlitman
Seat (rear seats) ***************22 lbs **goose42
Seat (front cloth, no airbag)******* 32 lbs **Speed4TheNeed
Seat (front leather, no airbag)******35 lbs **Speed4Theneed
Seat (front)******************* 37 lbs **goose42
Seatbelts (all 4, minus females)**** 9.5 lbs **Speed4TheNeed
Spare tire (donut) ************** 24 lbs **Jlitman
Spare tire (full size) ***** * * * * * 40 lbs **goose42
Steering wheel (w/airbag)***** * ***9 lbs **Speed4Theneed
Steering wheel ******************6 lbs **goose42

===Part 2. STOCK EXTERIOR===

Fender (each) * ** * * * * ** ** * * 5 lbs **Speed4Theneed
Hood (with scoop) **** **********23 lbs **Speed4Theneed
Mirros (both w/motor) ** ***** * * * 5 lbs **Speed4Theneed
Spoiler (regular)********* ** * * * *5 lbs **goose42
Tire (each -- 205/50/16) * * * * * **21 lbs **Jlitman
Wheel (16"--each)***************18 lbs **Jlitman
Wheel (all four 16" w/tires)********160 lbs **goose42

===Part 3. Stock Mechanical, Performance, Etc..===

A/C compressor & clutch ***********12 lbs **Speed4TheNeed
A/C condenser (no tubing)* ******** *5 lbs **Speed4TheNeed
A/C system (minus evaporator)*******21 lbs **goose42
Alternator **********************11 lbs **Speed4Theneed
Battery*** *** *** ** *** ** *****33 lbs **goose42
Crankshaft (1ZZ)****** **** ******20 lbs **Speed4Theneed
Crankshaft (2ZZ)******* ** * * ****27 lbs **Speed4TheNeed
Cruise control******************** 6 lbs **Jlitman
Exhaust (GT-S axleback)***** ******27 lbs **Jlitman
Exhaust (GT-S axleback) ********* 27.5 lbs **Turbo Magazine (Speed4Theneed)
Exhaust************************25 lbs **goose42
Header (1ZZ w/heatshields)***** * ***9 lbs **Speed4TheNeed
Header************************* 9 lbs **goose42
Intake manifold (2zz)***** ******** 11 lbs **Jlitman
Radiator***************** *******4 lbs **Speed4TheNeed
Springs****** **** * ****** *****16 lbs **goose42
Windshield wiper (rear w/motor)*******3 lbs **goose42
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set

Last edited by Speed4TheNeed; 03-15-2006 at 06:02 PM..
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-15-2006, 04:47 PM   #18
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
If we are to categorize the AFTERMARKET/REPLACEMENT parts items, I beleive we should use much more categories than just 3 like the stock ones. Because there are so many of the same items (like exhausts, headers, bodykits, wheels, etc) it wouldn't be very intuitive to jam so many items into the same categories. It makes sense for stock because there is usually only 1 thing, and maybe a few at most..but for the aftermarket where there could be as many as 50 (just an example), it would make that category much too broad.

This is just an example (outline form) but it probably should go something like:

Category I: Appearance
--Subcategory A. Exterior
------Section 1. Bodykit components & Spoilers
------Section 2. Fenders, Hoods, & Hatches
------Section 3. Wheel & Tire
--Subcategory B. Interior
------Section 1. Seats & seat bases/rails/sliders
------Section 2. Everything else

Category II: Performance
--Subcategory A. Intakes, Exhausts, Headers, Pulleys, etc.
--Subcategory B. Suspension & Chassis
------Section 1. Springs, Shocks, Coilovers, Sway bars
------Section 2. Reinforcements (braces, roll cages, tower bars, etc)
--Subcategory C. Brakes & Drivetrain
------Section 1. Rotors, calipers, etc.
------Section 2. Flywheels, clutches, gears, etc.

This is just an example off the top of my head. I'm sure there's a much better way to keep everything organized but I do beleive organization is the key. Having a huge list isn't going to do anyone much good if they can't find things simply & intuitively.
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-15-2006, 09:04 PM   #19
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
Great job Speed! and I agree that some categorization is necessary for aftermarket. I suggest we find out what format Larry used for the parts catalog and stick with that so theres some continuity across the site.
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-16-2006, 11:33 AM   #20
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
^^ Sounds good to me, this is how LarryD does it:

1. Performance mods
------A. Intakes, Air filters
------B. Exhausts, Cats
------C. Headers
------D. Pulleys
------E. Engine Internals, Engine Hardware
------F. Turbochargers, Superchargers, Nitrous (combined)
------G. Other

2. Drivetrain
------A. Flywheels
------B. Clutches
------C. LSDs, Shift Kits, Gears (combined)

3. Suspension, Brakes
------A. Struts, Shocks, Springs, Coilovers (combined)
------B. Sway Bars, Misc. Suspension (combined)
------C. Chassis Braces
------D. Brake Pads, Rotors, Calipers, BBKs (combined)

4. Exterior Appearance
------A. Bodykit Components (bumpers, sides, lips)
------B. Hoods, Spoilers, Scoops (combined)
------C. Engine compartment, Other Miscellaneous (combined)

5. Interior Appearance
------A. Seats, Seat accessories, Harnesses (combined)
------B. Steering Wheels & Hubs
------C. Shift knobs, Pedal sets, Other Miscellaneous (combined)
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-16-2006, 11:49 AM   #21
celicagtsUSMC

Join Date: Mar 2006
Location: silverdale WA
Posts: 62
iTrader: (0)
does any one know how much the passenger air bag weighs
__________________
2000 celicagts sold
93 rx-7 love it
celicagtsUSMC is offline   View this Members' Photo Gallery Reply With Quote
Old 03-16-2006, 12:38 PM   #22
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
Boosted, the list below is the same AFTERMARKET/REPLACEMENT list as you have posted above, just categorized and alphabetized. The list was categorized using LarryD's "Product Catalog" on this site as a guide.

Blue = Main Category
Red = Sub Category
Orange = Input Category (If needed. Some sub-categories are singular, so they don't need an "orange" input category. Most Sub Categories are combined with other categories, though and therefore "orange" input categories are used to divide these up.

1. Performance mods


------A. Intakes, Air filters

Intakes:
AEM CAI w/filter************** *** **2 lbs **Speed4TheNeed
Injen CAI w/filter*** ** ** * ** * * **3.5 lbs **Speed4TheNeed


------B. Exhausts, Cats

Exhausts:
5Zigen Fireball**** *********** 26.5 lbs **Turbo Magazine (Speed4TheNeed)
A'PEXi N1********** **** ** **23.5 lbs **Turbo Magazine (Speed4Theneed)
Blitz*************************21 lbs **Turbo Magazine (Speed4TheNeed)
GReddy Evo 1*************** *35.5 lbs **Turbo Magazine (Speed4TheNeed)
GReddy Evo 2******************35 lbs **Jlitman
HKS Hi-Power****** ** *********28 lbs **Turbo Magazine (Speed4Theneed)
Magnaflow********* ***********20 lbs **goose42
Rod Millen*********************28 lbs **Turbo Magazine (Speed4TheNeed)
Tanabe Racing Medallion**********29 lbs **Turbo Magazine (Speed4TheNeed)
TRD Kazuma*******************20 lbs **Speed4Theneed
TRD (normal)****************** 25 lbs **Turbo Magazine (Speed4TheNeed)
Veilside Tear Drop (titanium)********8 lbs **Turbo Magazine (Speed4TheNeed)

------C. Headers
DC Sports ceramic (2ZZ)**********6.5 lbs **Speed4TheNeed
DC Sports*** * * ** ** *** *******5 lbs **goose42
TRD race long tube (2ZZ)*** ** **** 8 lbs **Speed4TheNeed
------D. Pulleys

------E. Engine Internals, Engine Hardware

Valves:
Supertech 2ZZ (all 16)*********** *1 lbs **Speed4TheNeed

Valve Springs:
Eibach 2ZZ (all 16)**************0.5 lbs **Speed4Theneed

Rods:
Crower MWR 2ZZ stroker (all four)* * *9 lbs **Speed4TheNeed

Pistons:
Wiseco 2ZZ 12.5:1 (all four)*******2.5 lbs **Speed4TheNeed

Sleeves:
Darton 2ZZ (all four)**************4 lbs **Speed4TheNeed

------F. Turbochargers, Superchargers, Nitrous (combined)

Superchargers:
GReddy (2ZZ complete kit)****************36 lbs **Jlitman

------G. Other
Radiators:
Koyo Racing****************************9 lbs **Speed4TheNeed

Oil Coolers:
TRD 2ZZ******************** ** ******1.5 lbs **Speed4TheNeed

Oil Pans:
Moroso 1ZZ/2ZZ****************** *****10 lbs **Speed4TheNeed




2. Drivetrain


------A. Flywheels
AASCO (aluminum)********************8.0 lbs.
Blitz Active Clutch (chromoly)* **** **** 10.5 lbs.
C-One (chromoly)******************* 9.92 lbs.
Fidanza (aluminum)GT-S****************7.5 lbs.
Fidanza (aluminum) GT********* **** ***8.5 lbs
Gripforce (chromoly)***************** 11.0 lbs.
JUN (chromoly)********************** 9.7 lbs.
Mueller (aluminum)******** *********** 8.0 lbs.
MWR (forged chromoly) GT-S* ** * ***** 10.5 lbs.
MWR (forged chromoly) GT*************10.2 lbs.
RPS Cyn-R-G Segmented (aluminum) * * * * 9.5 lbs.
Toda (chromoly)******************* 10.36 lbs.
TOM's (chromoly)********************8.03 lbs.
TRD Japan Flywheel (chromoly)********** 9.6 lbs.
Unorthodox (aluminum)*****************8.0 lbs.


------B. Clutches
RPS Max (pressure plate)***************7.9 lbs

------C. LSDs, Shift Kits, Gears (combined)


3. Suspension, Brakes


------A. Struts, Shocks, Springs, Coilovers (combined)

Springs:
Hotchkis (all four)************ *** ***** 24 lbs **goose42
TRD (all four)*************************20 lbs **Speed4TheNeed

Shocks:
TRD (all four)*************************24 lbs **Speed4Theneed


------B. Sway Bars, Misc. Suspension (combined)

Sway Bars:
Hotchkis Street (both)*******************9 lbs **Speed4TheNeed
TRD (both)********* *****************17 lbs **Speed4TheNeed

Camber links:
Hotchkis rear (both)*********** *** ***** 5 lbs **Speed4TheNeed

Endlinks:
Hotchkis (all four)********************** 4 lbs **Speed4TheNeed


------C. Chassis Braces

Chassis Braces:
APR front strut bar********************* 4 lbs **Jlitman
C-One trunk bar*********************** 3 lbs **Jlitman
TRD rear strut bar*** **** ** *** ********5 lbs **Jlitman


------D. Brake Pads, Rotors, Calipers, BBKs (combined)


4. Exterior Appearance


------A. Bodykit Components (bumpers, sides, lips)

------B. Hoods, Spoilers, Scoops (combined)

Hoods:
C-One ver.2 carbon fiber**************9 lbs **KamiSpeed (Speed4TheNeed)
Varis Cooling carbon fiber* ** * *** **14.3 lbs **KamiSpeed (Speed4Theneed)

Hatches:
ViS OEM style*********************10 lbs **Speed4TheNeed

------C. Engine compartment, Other Miscellaneous (combined)

Batteries:
Braille Race************* **** * * 11.5 lbs **Speed4TheNeed
Braille All Season****** ****** ** ***15 lbs **Speed4TheNeed
Hawker Odyssey*******************15 lbs **goose42]

------D. Wheel & Tire, Accessories

Wheels:
Rota Subzero 15" (each)****** *****12.8 lbs **Jlitman
Volk CE-28n 16 X 7 (each)**********10.5 lbs **Speed4TheNeed

Tires:
Toyo T1-S 195/55/15 (each)********16.5 lbs **Jlitman

Wheel/Tire Sets:
Icon 17"/Kumho (full set) ***********152 lbs **goose42


Lug nuts:
Rays lightweight (all 20)* *** * ** *****1 lbs **Speed4Theneed


5. Interior Appearance


------A. Seats, Seat accessories, Harnesses (combined)

Seats:
APC F1*********************** **** 35 lbs **Speed4TheNeed
Momo RS GT********************** 16.2 lbs **Speed4TheNeed
Momo RS2 GT**********************21.2 lbs **Speed4TheNeed
Momo Strt Rcr GT********* ** * *** * 25.4 lbs **Speed4TheNeed
Recaro Profi SPA**********************8 lbs **Speed4TheNeed
Sparco Circuit***********************25 lbs **Speed4TheNeed
Sparco Corsa*********************** 22 lbs **Speed4TheNeed
Sparco Evo*********************** 18.5 lbs **Speed4TheNeed
Sparco Evo (carbon fiber)*************12.5 lbs **Speed4TheNeed
Sparco Evo 2******************* ** 18.5 lbs **Speed4TheNeed
Sparco Evo 3******************* ****22 lbs **Speed4TheNeed
Sparco Fighter********************** 20 lbs **Speed4TheNeed
Sparco Milano ********************** 44 lbs **Speed4TheNeed
Sparco Milano 2********************* 44 lbs **Speed4TheNeed
Sparco Milano Prestige**************** 48 lbs **Speed4TheNeed
Sparco Monza***********************40 lbs **Speed4TheNeed
Sparco Pro************************21.5 lbs **Speed4TheNeed
Sparco Pro (carbon fiber)***************13 lbs **Speed4TheNeed
Sparco S-Light********************** 25 lbs **Speed4TheNeed
Sparco Sienna***********************30 lbs **Speed4TheNeed
Tenzo R********** * ***** ** * ** ***26 lbs **goose42

Bases, Sliders, Brackets, etc:
Recaro bases, sliders, side mounts (both)***35 lbs **Speed4TheNeed

------B. Steering Wheels & Hubs

Steering Wheels:
OMP*******************************4 lbs **goose42


------C. Shift knobs, Pedal sets, Other Miscellaneous (combined)
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set

Last edited by Speed4TheNeed; 03-16-2006 at 05:03 PM..
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-16-2006, 05:04 PM   #23
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
Compliments of DeltaB

Stock GT-S Flywheel: 13.38 lbs
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-16-2006, 07:29 PM   #24
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
updated - thanks for all the hard work Speed!
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-17-2006, 07:11 PM   #25
Monster Hui

Join Date: Jan 2003
Location: Victoria BC Canada
Posts: 257
iTrader: (3)
Send a message via ICQ to Monster Hui
got a few stock parts that i just weighted... I'll have more weights of other aftermarket parts in the near future.. here's my contribution to the thread so far

stock moonroof: 11lbs
stock moonroof tracks with motor: 14lbs
side passenger airbag with cover plastic panel: 7.5lbs
stock rear hatch with struts (no glass): 33lbs
stock sun visors (pair): ~1lbs

wheels/tires:
Volk CE28N 17x7.5: 13.5lbs each
SSR Competition 16x6.5: 11.5lbs each
Yokohama A048 M compound 215/45 17: 22.5lbs each
Yokohama A032 H compound 205/55 16: 22.5lbs each
Yokohama A032 H compound 225/50 16: 25lbs each
Kumho V710 225/50 16: 23.5lbs each
__________________
Celica Garage
REVscene.net

Monster Hui is offline   Reply With Quote
Old 03-17-2006, 10:22 PM   #26
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
Awesome! Thanks!

Just for verification but is the stock moon roof you are speakign of glass or Lexan? ('00-'02 Celicas use Lexan, '03+ Celicas use glass).

I have both types in my possession..I didn't even think about weighing them. Whichever one you didn't weigh I'll get out and on a scale so we'll have both listed.
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-17-2006, 10:33 PM   #27
RYTEK

Join Date: Jun 2005
Location: Ft. Myers FL
Posts: 165
iTrader: (1)
Dose anyone know how much the stock rear hatch glass alone weighs...

I just want to see how many pounds ill save when I replace the hood and hatch with carbon fiber units, using the stock glass. 36 lbs is what I came up with. just wondering if it would be worth replacing the glass with like plexiglass or something Thanks!...
RYTEK is offline   View this Members' Photo Gallery Reply With Quote
Old 03-17-2006, 10:37 PM   #28
RYTEK

Join Date: Jun 2005
Location: Ft. Myers FL
Posts: 165
iTrader: (1)
To save money, I think clear coating the plastic replacement would be chaper than getting a scrach resistant lexan glass, then maybe I could use something even lighter...
RYTEK is offline   View this Members' Photo Gallery Reply With Quote
Old 03-18-2006, 02:14 AM   #29
Monster Hui

Join Date: Jan 2003
Location: Victoria BC Canada
Posts: 257
iTrader: (3)
Send a message via ICQ to Monster Hui
Quote:
Originally Posted by Speed4TheNeed
Awesome! Thanks!

Just for verification but is the stock moon roof you are speakign of glass or Lexan? ('00-'02 Celicas use Lexan, '03+ Celicas use glass).

I have both types in my possession..I didn't even think about weighing them. Whichever one you didn't weigh I'll get out and on a scale so we'll have both listed.
it was the lexan one.. i was actually surprised by the weight, heavier than i thought being lexan and all, but it -is- pretty thick


Quote:
Originally Posted by RYTEK
To save money, I think clear coating the plastic replacement would be chaper than getting a scrach resistant lexan glass, then maybe I could use something even lighter...
a scratch resistant lexan (dual side) glass cut for the celica is about 150 or less... it will be a pretty big weight saving compare to stock glass and it's strong, plastic or other clear material may deteriorate quicker over time in comparison.. and by the time you replace the 2nd piece of plastic (after getting a glass shop to cut out the plastic and clean up the surface on the cf and installing a new piece of glass in), you would have paid about the same as getting a quality lexan put in in the first place

if you want to save more weight in the hatch area, take out to latching system and just use hatch-locks
__________________
Celica Garage
REVscene.net

Monster Hui is offline   Reply With Quote
Old 03-18-2006, 08:22 PM   #30
RYTEK

Join Date: Jun 2005
Location: Ft. Myers FL
Posts: 165
iTrader: (1)
about $150 for a lexan replacement? thats actually cheaper than I expected... how much lighter is it? worth it???
RYTEK is offline   View this Members' Photo Gallery Reply With Quote
Old 03-18-2006, 09:35 PM   #31
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
Quote:
Originally Posted by Monster Hui
got a few stock parts that i just weighted... I'll have more weights of other aftermarket parts in the near future.. here's my contribution to the thread so far

stock moonroof: 11lbs
stock moonroof tracks with motor: 14lbs
side passenger airbag with cover plastic panel: 7.5lbs
stock rear hatch with struts (no glass): 33lbs
stock sun visors (pair): ~1lbs

wheels/tires:
Volk CE28N 17x7.5: 13.5lbs each
SSR Competition 16x6.5: 11.5lbs each
Yokohama A048 M compound 215/45 17: 22.5lbs each
Yokohama A032 H compound 205/55 16: 22.5lbs each
Yokohama A032 H compound 225/50 16: 25lbs each
Kumho V710 225/50 16: 23.5lbs each
Updated! Thanks for the great info!
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-19-2006, 12:59 AM   #32
Monster Hui

Join Date: Jan 2003
Location: Victoria BC Canada
Posts: 257
iTrader: (3)
Send a message via ICQ to Monster Hui
Quote:
Originally Posted by RYTEK
about $150 for a lexan replacement? thats actually cheaper than I expected... how much lighter is it? worth it???
i was considering putting the lexan in, had the lexan guys to cut a cardboard template already for me and gave me the quote for $180 canadian dollars (i live in canada) for a double sided lexan cut... so that's about 150 usd (but i'd say it should be between 150-200 just to be safe) No shapping required because it is thin enough that the weight of itself can curve to the hatch's curvature. I never had it made however, since if i go lexan i'd get bumped up into another class at the autocross circuit.. so i just kept the stock glass and never got the lexan to find out how much it'd weight.

just got a few more things weighted
stock crankpully for 2zz: 3.5lbs
stock rear upper control arms (pair): 5.5lbs

Blitz SUS power type LM intake (short ram intake): 2.5lbs

oh and boosted2.0, i think for the weight in for the whole car, we need to specify the transmission too since a stock MT to an AT celica is ~100lbs difference
__________________
Celica Garage
REVscene.net


Last edited by Monster Hui; 03-19-2006 at 01:22 AM..
Monster Hui is offline   Reply With Quote
Old 03-19-2006, 04:54 AM   #33
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
AEM alternator pulley: 1 lb
Unorthodox alternator pulley: 1 lb

I'll have the Unorthodox crank pulley, 1ZZ intake manifold & throttle body, 2ZZ throttle body, and glass sunroof weighed by tomorrow. Maybe today but Sundays are usually a bad day for me to get things done.
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-19-2006, 09:37 AM   #34
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
Compliments of pnoy:

Veilside FFGT carbon fiber hood: 15 lbs
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-22-2006, 08:38 AM   #35
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
Quote:
Originally Posted by Monster Hui
i was considering putting the lexan in, had the lexan guys to cut a cardboard template already for me and gave me the quote for $180 canadian dollars (i live in canada) for a double sided lexan cut... so that's about 150 usd (but i'd say it should be between 150-200 just to be safe) No shapping required because it is thin enough that the weight of itself can curve to the hatch's curvature. I never had it made however, since if i go lexan i'd get bumped up into another class at the autocross circuit.. so i just kept the stock glass and never got the lexan to find out how much it'd weight.

just got a few more things weighted
stock crankpully for 2zz: 3.5lbs
stock rear upper control arms (pair): 5.5lbs

Blitz SUS power type LM intake (short ram intake): 2.5lbs

oh and boosted2.0, i think for the weight in for the whole car, we need to specify the transmission too since a stock MT to an AT celica is ~100lbs difference
Good call on the Tranny!
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-22-2006, 09:12 AM   #36
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
Thread updated
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-22-2006, 01:21 PM   #37
E13

Join Date: May 2004
Location: Lexington, Ky
Posts: 681
iTrader: (11)
2004 6speed GTS tranny 76lbs I remember this cuz I had one shipped to me.
ADD this in and then I will delete this message.
__________________
2006 S2000: U.R. pulleys, Fidanza flywheel, J's header, J's racing LSD and 4.7 final drive, T1R 70mm single, 244whp Untuned.
E13 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-23-2006, 12:49 PM   #38
superman1240

Join Date: Aug 2002
Location: Salinas CA
Posts: 684
iTrader: (3)
got some doors with lexan windows.....it should be lighter than this but this is minus the weight of the difference of the doors to the last time i weighed it.

1930 lb *** 2002 GTS *** almost empty tank *** Manual *** superman1240
__________________
Image hosted by Photobucket.com

[email protected] N/A
superman1240 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-23-2006, 08:22 PM   #39
Shizuma
Professional Carsmith

Join Date: Mar 2005
Location: Houston, TX
Posts: 6,311
iTrader: (42)
Send a message via AIM to Shizuma
Quote:
Originally Posted by superman1240
got some doors with lexan windows.....it should be lighter than this but this is minus the weight of the difference of the doors to the last time i weighed it.

1930 lb *** 2002 GTS *** almost empty tank *** Manual *** superman1240
wow that's a REALLY good weight...that's near Elise territory....what all have you removed from your car?
__________________
Shizuma is offline   View this Members' Photo Gallery Reply With Quote
Old 03-23-2006, 08:26 PM   #40
Shizuma
Professional Carsmith

Join Date: Mar 2005
Location: Houston, TX
Posts: 6,311
iTrader: (42)
Send a message via AIM to Shizuma
oh BTW I got all the sound deadening material out of the driver, passenger, rear seats, and hatch (still have to take off the dash and remove the rest) but so far the weight (including the rubber like stuff from underneath the center console) is 18 lbs
__________________
Shizuma is offline   View this Members' Photo Gallery Reply With Quote
Old 03-23-2006, 09:14 PM   #41
elcelicagts

Join Date: Feb 2006
Location: southern ca.
Posts: 1,365
iTrader: (2)
this is all good info.... BUT what about someone getting all these numbers and picking the more pratical stock items to remove-
ADD them up, SUBTRACT the total weigth of the lightest aftermarket parts (replacing some of the stock parts removed). SUBTRACT that total with the stock Gts celicas normal weight to get = the cars new capable weight.

from what i see i bet we can shave off at least 200 pounds without going a lil over board with the weight reduction. back seats and spare tires alone remove around 100 pounds total weight loss to the cars weight. just plain cool.
elcelicagts is offline   View this Members' Photo Gallery Reply With Quote
Old 03-23-2006, 09:32 PM   #42
jlitman

Join Date: Oct 2004
Location: Under a red sun
Posts: 11,169
iTrader: (42)
Quote:
Originally Posted by Monster Hui
oh and boosted2.0, i think for the weight in for the whole car, we need to specify the transmission too since a stock MT to an AT celica is ~100lbs difference
Bit less than that, and varies according to model:

Curb weight (manual/automatic)
GT: 2,425/2,460 lbs.
GT-S: 2,500/2,580 lbs.
__________________
jlitman is offline   View this Members' Photo Gallery Reply With Quote
Old 03-24-2006, 04:15 PM   #43
milesplume

Join Date: Jun 2005
Location: rocklin, california
Posts: 611
iTrader: (1)
yes i am curious as to how u got ur celica to weigh 1930lb please do tell
__________________
i will not tiptoe through life to arrive at death safely!Spider Monkey Celica GT-SImage hosted by Photobucket.com
milesplume is offline   View this Members' Photo Gallery Reply With Quote
Old 03-24-2006, 04:55 PM   #44
milesplume

Join Date: Jun 2005
Location: rocklin, california
Posts: 611
iTrader: (1)
k guys i thought the wheel weight section needed adding too well i have these weights how it is ordered is like this

name/type rim fabrication/dimensions/weight

this is like every rim in existance or something and i put them all in abc order for u later
-milesplume
562 Fuel Cast 17x7 26.5
562 Kabuki Cast 17x7 27.0
5Zigen 5ZR Copse Cast/Spun 16x7 15.7
5Zigen 5ZR Copse Cast/Spun 17x7 23.0
5Zigen 5ZR Copse Cast/Spun 17x7.5 23.5
5Zigen 5ZR Copse Cast/Spun 18x10 26.0
5Zigen Beckets FN-01R Forged 15x7 10.6
5Zigen Beckets FN-01R Forged 16x7 11.7
5Zigen Beckets FN-01R Forged 17x7.5 13.9
5Zigen Beckets FN-01R Forged 17x8 14.7
5Zigen Beckets FN-01R Forged 17x8.5 15.4
5Zigen Beckets FN-01R Forged 17x9 15.6
5Zigen Beckets FN-01R Forged 17x9.5 15.8
5Zigen Copse Cast 15x7 11.0
5Zigen DIV.3 Cast 15x6.5 12.6
5Zigen Fireball Cast 17x7 18.0
5Zigen Fireball Typhoon Cast 17x7.5 21.5
5Zigen Fireball Typhoon Cast 17x8 22.0
5Zigen Fireball Typhoon Cast 17x9 22.5
5Zigen FN01R-C Cast 15x7 14.0
5Zigen FN01R-C Cast 16x7 15.0
5Zigen FN01R-C Cast 17x10 21.5
5Zigen FN01R-C Cast 17x7 16.0
5Zigen FN01R-C Cast 17x8 17.0
5Zigen FN01R-C Cast 17x9 19.0
5Zigen FN01R-C Cast 18x7.5 18.5
5Zigen FN01R-C Cast 18x8.5 21.5
5Zigen FN01R-C Cast 18x9.5 23.0
5Zigen Heidfeld Cast 17x7 19.0
5Zigen Heidfeld Cast 18x7.5 20.0
5Zigen Heidfeld 2-Piece Cast/Spun 17x7.5 24.3
5Zigen Hyper 5zr Cast 18x7.5 25.5
5Zigen Imperio M05 Cast 17x7 19.0
5Zigen Imperio M05 Cast 18x7.5 20.5
5Zigen Imperio S08 Cast 16x7 19.8
5Zigen Imperio S08 Cast 17x7 20.5
5Zigen N1R-SP08 Cast 15x6.5 14.1
5Zigen N1R-SP08 Cast 17x7 17.5
5Zigen ProRacer GN+ Cast 17x7.5 20.0
5Zigen Super Six Cast 17x7 19.0
5Zigen Typhoon Cast 17x7.5 21.5
5Zigen Typhoon Cast 17x8 22.0
5Zigen Typhoon Cast 17x9 22.5
6061 A5 Forged 17x7 14.5
6061 A5 Forged 19x7.5 18.5
6061 A5LW Forged 17x7 13.5
6061 A5LW Forged 19x7.5 15.0
6061 AM Forged 19x7.5 16.5
ABT Sportsline A-10 Cast 18x8 24.0
ABT Sportsline A-16 Cast 17x8 24.8
ABT Sportsline A-23 Cast 17x7.5 22.5
ABT Sportsline New Classic Cast 18x8 26.0
ABT Sportsline V1 Cast 17x7.5 21.3
AC Schnitzer (front) Forged 20x10 22.0
AC Schnitzer (rear) Forged 20x10 23.8
Ace A109 (Formula) Cast 17x7 25.0
Ace A130 (Spyder) Cast 18x8.5 23.0
Ace A131 (Lola) Cast 17x7 23.5
Ace A134 (Turbo) Cast 17x7 20.5
Ace A137 (Flame) Cast 18x8.5 31.5
Ace A151 (Spade) Cast 18x7.5 23.0
Ace A157 (Monaco) Cast 19x8 27.3
Ace A164 (Desire) Cast 18x8.5 26.5
Ace A204 (Impact) Cast 17x7 19.0
Ace A204 (Impact) Cast 19x8 24.0
Ace A205 (Manta) Cast 19x8 26.6
Ace Desire Cast 18x8.5 27.3
Acura Integra GS 92 Cast 14x5.5 15.5
Acura Integra GS-R 94-95 Cast 15x6 16.0
Acura Integra GS-R 96 Cast 15x6 15.5
Acura Integra GS-R 97 (00+ LS) Cast 15x6 15.0
Acura Integra GS-R 98-01 Cast 15x6 16.3
Acura Integra Type-R (Euro 5-bolt) Cast 15x6 13.0
Acura Integra Type-R (JDM 4-bolt) Cast 15x6 12.3
Acura Integra Type-R (JDM 4-bolt) Cast 16x7 17.0
Acura Integra Type-R (US 5-bolt) Cast 15x6 15.6
Acura NSX Forged 15x6.5 15.2
Acura NSX Forged 16x7 16.8
Acura NSX Forged 16x8 18.9
Acura NSX Forged 17x8.5 20.9
Acura RSX 02-04 Cast 16x6.5 16.0
Acura RSX 05-06 Cast 17x7 21.0
Adler Racing AR05A Cast 16x7 15.7
Adler Racing AR08 Cast 16x7 15.7
ADR 39 (Intercrew) Cast 17x7 20.3
ADR 42 (M-Classic) Cast 20x8.5 29.8
ADR 43 (X-Factor) Cast 19x8 27.8
ADR Battle Axe Cast 17x7 22.5
ADR Cobra Cast 17x9 26.0
ADR DTM Cast 16x7 19.0
ADR Hypertek Cast 17x7 19.0
ADR Kasai Cast 18x8 22.8
ADR Lightning Cast 17x7 25.5
ADR M-Sport Cast 18x7.5 22.2
ADR Reaction Cast 16x7 19.9
ADR Reaction Cast 18x7.5 24.3
ADR Revolution Cast 17x7 20.5
ADR RS Limited Concept Pro Cast 15x6.5 13.0
ADR RS Limited Concept Pro Cast 16x7 16.5
ADR RS Limited Concept Pro Cast 17x7 18.0
ADR RS Limited Mase Cast 17x7 17.5
ADR RS Limited Mase Cast 18x7.5 19.5
ADR RS Limited Ricochet Cast 17x7 19.4
ADR RS Limited Shinwa Cast 16x7 15.0
ADR RS2000 Cast 17x7 21.0
ADR RS2000 Cast 18x8 23.0
ADR Version II Cast 18x8 28.6
Advan Kreuzer Series X Cast 18x8 16.5
Advan Model 5 Cast 18x8 19.8
Advan Model 7 Cast 15x5.5 12.3
Advan Model 7 Cast 19x9 27.0
Advan Racing RA3-DT Cast 17x9.5 18.5
Advan Racing RA3-DT Cast 18x10 20.5
Advan Racing RC Rally Cast 17x7 18.5
Advan Racing RG Cast 14x6 8.9
Advan Racing RG Cast 14x6.5 9.9
Advan Racing RG Cast 15x6.5 10.5
Advan Racing RG Cast 15x7 11.4
Advan Racing RG Cast 15x7.5 12.1
Advan Racing RG Cast 15x8 12.6
Advan Racing RG Cast 16x7 12.7
Advan Racing RG Cast 16x7.5 13.4
Advan Racing RG Cast 16x8 13.8
Advan Racing RG Cast 17x7.5 15.2
Advan Racing RG Cast 17x8.5 16.5
Advan Racing RG Cast 17x9.5 17.9
Advan Racing RG Cast 18x9 19.0
Advan Racing TC Cast 18x7.5 19.8
Advan Siena Generation II Cast 18x10 25.0
Advan Super Advan Generation II Cast 18x9.5 25.5
Advan Super Advan Racing SA3R Cast 17x8 23.5
Advanti Racing 976 Cast 17x7 21.8
Advanti Racing Battle Z Cast 17x7 22.0
Advanti Racing Jazz Cast 16x7 18.5
Advanti Racing Lightening Cast 17x7 23.5
Advanti Racing Tuner 6 Cast 17x7 18.0
Aerospeed RS-11 Cast 17x7 21.4
Aerospeed RS-12 Cast 17x7 23.5
Aerospeed RS-14 Cast 17x7 20.5
Aerospeed RS-6 Cast 17x7 23.0
AEZ Bimo Cast 18x8.5 26.8
AEZ Paron Cast 18x8.5 27.4
AEZ Radon Cast 16x7.5 19.0
AEZ Simas X Cast 18x8.5 30.5
AFX Ambush 750 Cast 20x8.5 33.0
AFX Wedge Cast 17x7.5 27.5
AK Tires Monza Cast 15x6.5 13.0
AK Tires Monza Cast 16x6.5 14.5
Akuza 209 Siege Cast 17x7.5 21.0
Akuza 209 Siege Cast 18x8.5 25.6
Akuza Z18 Sublime Cast 19x8.5 31.8
Alba 530 Cast 18x7.5 27.3
Alba 540 (Lexo) Cast 18x7.5 27.6
Alba 707 (Bertha) Cast 18x7.5 33.0
Alba 804 (Delta) Cast 18x8.5 33.3
Alba 907(Blaze) Cast 20x8.5 31.5
Alba Helix Cast 17x7.5 26.5
Alba R-510 Cast 17x7.5 22.0
Alba Wolverine Cast 17x7.5 27.0
Alfa Romeo Cast Mg 13x5.5 9.0
Alfa Romeo 156 Cast 16x6.5 21.7
Alfa Romeo GTV Cast 17x7.5 25.3
ALT 148 Cast 15x6.5 16.5
ALT AT-186 Cast 17x7 24.0
ALT AT-210 Cast 16x7 15.5
ALT AT-213 Cast 17x7 19.0
ALT AT-226 (Ciber) Cast 18x7.5 21.6
ALT AT-228 (Fusion) Cast 18x8 25.8
ALT Seven Cast 17x7 23.0
ALT Slash Cast 17x7 22.3
ALT X-phile Cast 17x7 20.8
Altstadt IV Cast 18x8.5 24.5
Altstadt Mesh Cast 18x8 27.5
American Eagle 077 Cast 17x8 22.0
American Eagle 135 Cast 17x7.5 20.0
American Eagle 168 (Cobra) Cast 17x9 24.0
American Racing AR-210 (Zurg) Cast 16x7 19.5
American Racing AR-222 (Pinzetti) Cast 16x7 20.0
American Racing AR-222 (Pinzetti) Cast 17x7 22.5
American Racing AR-245 (Twisted Tuner) Cast 16x7 21.5
American Racing AR-245 (Twisted Tuner) Cast 18x7 24.0
American Racing AR-50 Cast 16x7 17.5
American Racing AR-55 (Spyder) Cast 14x6 15.0
American Racing AR-55 (Spyder) Cast 15x7 15.9
American Racing AR-55 (Spyder) Cast 16x7 17.0
American Racing AR-95 (Estrella) Cast 14x6 13.5
American Racing AR-95 (Estrella) Cast 15x7 18.0
American Racing AR-95 (Estrella) Cast 16x7 20.0
American Racing Libre Cast 14x5.5 13.5
AMG Monoblock Cast 17x7.5 27.5
AMG Monoblock Cast 17x8.5 28.0
Anterra Type 145 Cast 17x7 25.0
Anterra Type 161 Cast 17x7 29.0
Anterra Type 163 Cast 18x8 33.0
Anterra Type 165 Cast 18x7.5 24.2
Anterra Type 183 Cast 18x8 30.8
Anterra Type 309 Cast 18x8 27.4
Arbet III Cast 17x7 25.0
Arbet V Cast 15x7 21.0
Arceo Eurostar Cast 18x7.5 23.8
Arceo Megastar Cast 19x8 29.8
Arelli Bling-Bling (Type 101) Cast 20x8.5 34.0
Arelli Czar Cast 18x7.5 27.5
Arelli DeLemma Cast 20x8.5 38.8
Arelli Kaz'mir Cast 18x8.5 30.0
Arelli Pulse Cast 17x7 24.0
Arelli Q Cast 17x7 26.0
Arelli Sensei Cast 20x8.5 33.8
Arelli Tranz Cast 18x8.5 26.5
Arelli Type 170 Cast 17x7.5 26.0
Arospeed RS11 Cast 17x7 18.5
Arospeed RS17 Cast 17x7 20.2
Arospeed RS23 Cast 17x7 18.0
Arospeed RS-GT Cast 18x7.5 22.8
ASA AR1 Cast 15x6.5 15.9
ASA AR1 Cast 16x7 18.1
ASA AR1 Cast 17x7 20.7
ASA AR1 Cast 18x7.5 22.5
ASA AR1 Cast 18x8.5 23.0
ASA EM9 Cast 15x7 19.0
ASA EM9 Cast 16x7 19.5
ASA EM9 Cast 17x7 21.0
ASA FR1 Forged 17x7 16.5
ASA FR1 Forged 17x8 18.0
ASA JH2 Cast 18x7.5 24.3
ASA JH6 Cast 16x7 18.0
ASA JH6 Cast 17x7 19.0
ASA JS1 Cast 15x7 17.0
ASA JS1 Cast 16x7 18.0
ASA JS1 Cast 17x7 20.5
ASA JS5 Cast 15x7 18.0
ASA JS5 Cast 16x7.5 20.0
ASA JS5 Cast 17x7 21.5
ASA JS5 Cast 18x8 23.0
ASA JS6 Cast 15x7 19.5
ASA JS6 Cast 16x7 20.5
ASA JS6 Cast 17x7 22.5
ASA KA3 Cast 17x7.5 23.4
ASA LS5 Cast 16x7 17.0
ASA LS5 Cast 17x7 17.4
ASA LW5 Cast 15x7 14.5
ASA LW5 Cast 16x7.5 16.0
ASA LW5 Cast 17x7.5 17.2
ASA ST2 Cast 18x8 26.5
ASA ST3 Cast 18x8 25.6
ASA ST4 Cast 18x8 26.0
AT Italia 10 Razze Cast 16x7.5 20.5
AT Italia 10 Razze Cast 17x7.5 22.0
AT Italia Alp Cast 16x7.5 23.5
AT Italia Alp Cast 17x7.5 25.8
AT Italia Alp Cast 18x8 27.0
AT Italia Flash Cast 17x8 25.4
AT Italia Flash Cast 18x8 27.0
AT Italia Riva Cast/Spun 16x7.5 23.5
AT Italia Riva Cast/Spun 17x8 26.0
AT Italia Riva Cast/Spun 18x8 27.0
AT Italia S5 Cast 17x7.5 26.0
AT Italia S5 Cast 18x8 27.0
ATA H10 Cast 17x7.5 28.5
ATA H20 Cast 17x7.5 25.0
ATA H20 Cast 18x8.5 28.8
ATA H30 Cast 18x7.5 28.4
ATP 5 Razze Cast 16x7 23.3
ATP Flashsports Cast 18x8 26.0
ATP PT5 Cast 17x7.5 28.3
ATP Spa Cast 17x7 24.5
ATP Spa Cast 17x8.5 25.8
ATS 2000 DTM Cast 17x7.5 20.8
ATS Cetus Cast 18x8 26.5
ATS Cup Cast 15x7 17.0
ATS DTC Comp Lite Cast 15x8 13.8
ATS DTC Motorsport Cast 15x7 12.3
ATS DTC Motorsport Cast 15x8 13.2
ATS DTC Motorsport Cast 17x7.5 18.9
ATS DTC Motorsport Cast 17x9 19.4
ATS DTC Motorsport Cast 18x8.5 19.8
ATS DTM Comp Cast 17x7 20.8
ATS DTM Comp Cast 17x7.5 21.8
ATS DTM Comp Cast 17x9 24.9
ATS DTM Comp Cast 18x7 23.3
ATS DTM Comp Cast 18x8 22.4
ATS DTM Comp Racing Cast 17x7.5 19.4
ATS DTM Comp Racing Cast 17x9 20.2
ATS DTM Comp Racing Cast 18x7 19.1
ATS DTM Comp Racing Cast 18x8 19.8
ATS Epsilon Cast 17x8 21.4
ATS Planet Cast 16x7 18.8
ATS Planet Cast 18x8 25.0
Audi A4 5-spoke Cast 16x7 20.0
Audi A4 7-spoke Cast 16x7 20.6
Audi A8 Forged 17x8 21.0
Audi A8 9-spoke Cast 20x8.5 28.6
Audi S4 Avus Cast 17x7.5 28.0
Audi S8 Avus Cast 18x8 27.2
Audi TT Cast 16x7 18.5
Audi TT Forged 17x7.5 21.5
Audi TT Cast 17x7.5 29.0
Autobahn International C2 Cup Cast 17x7.5 21.5
Autobahn International Twisted Spoke Cast 18x9.5 31.5
Axis Crux Cast 17x7 19.8
Axis Crux Cast 18x7.5 21.6
Axis Crux Cast 19x8 25.0
Axis Decade Cast 18x8 22.5
Axis GT-R Cast 20x10.5 31.5
Axis GT-R Cast 20x9 27.0
Axis Hiro Cast 18x8.5 22.4
Axis Hiro Cast 19x10.5 26.9
Axis Hiro Cast 19x8.5 26.8
Axis Hiro Cast 19x9.5 27.0
Axis Kent Cast 22x10 42.0
Axis Mach V Cast 16x7 20.0
Axis Mach V Cast 18x7.5 26.0
Axis Mag-Lite Cast 15x7 12.6
Axis Mag-Lite Cast 17x7 15.6
Axis Mesh Cast 16x7 20.0
Axis Mesh Cast 17x7 22.5
Axis Milano Plus Cast 19x8.5 25.0
Axis Milano Plus Cast 19x9.5 26.0
Axis Milano Plus Cast 20x8.5 28.0
Axis Milano Plus Cast 20x9.5 28.5
Axis MOD Cast 18x7.5 20.8
Axis MOD Cast 19x8 25.5
Axis MOD Cast 20x10 28.1
Axis MOD Cast 20x9 26.1
Axis Mulliner Cast 22x10.5 39.4
Axis Mulliner Cast 22x9 35.8
Axis Ne-O Cast 17x7 20.8
Axis Ne-O Cast 19x8 26.3
Axis Orden Cast 20x10 29.7
Axis Orden Cast 20x8.5 29.5
Axis Orden Cast 22x10.5 38.6
Axis Orden Cast 22x9 38.0
Axis Penta Cast 19x8.5 24.8
Axis Penta Cast 19x9.5 25.4
Axis Phin Cast 19x8.5 23.0
Axis Phin Cast 19x9.5 25.0
Axis Regulator Cast 15x7.5 17.3
Axis Regulator Cast 16x9 19.6
Axis Regulator Cast 17x10 23.2
Axis Reverb Cast 17x7.5 18.0
Axis Reverb Cast 18x10.5 22.0
Axis Reverb Cast 18x7.5 19.0
Axis Reverb Cast 18x8.5 20.0
Axis Reverb Cast 18x9.5 22.6
Axis Reverb Cast 20x7.5 21.5
Axis Seven Cast 19x8 24.3
Axis Speed Six Cast 19x8 26.0
Axis Starz Cast 17x7 21.8
Axis TC Evo Cast 18x7.5 23.0
Axis TC Evo Cast 19x8 24.6
Axis Titan Cast 20x9 34.5
Axis Titan Cast 22x9 41.0
Axis Touring Cup Cast 16x7 20.0
Axis Touring Cup Cast 18x7 23.0
Axis VIP Cast 20x8.5 28.2
Axis VIP Cast 20x9.5 28.5
Axis Warlock Cast 17x10 26.1
Axis Warlock Cast 20x10 38.5
Axis WSM2 Cast 17x7 20.2
Azev Type H Cast 18x8 27.5
Azev Type LS Cast 18x8.5 27.6
Azev Type M Cast 18x8.5 32.4
Azzur Matrix Cast 20x8.5 33.0
BBS CH Cast 18x8 24.0
BBS CH Cast 18x8.5 24.5
BBS CH Cast 19x10 28.2
BBS CH Cast 19x8.5 25.7
BBS DTM Forged 17x7.5 17.9
BBS DTM Forged 17x8 18.3
BBS DTM Forged 17x9 19.6
BBS DTM Forged 18x10.5 23.8
BBS DTM Forged 18x7.5 19.8
BBS DTM Forged 18x8.5 21.4
BBS DTM Forged 18x9.5 21.8
BBS DTM Forged 19x10.5 25.8
BBS DTM Forged 19x9.5 24.7
BBS Elise (sector 111) Forged 16x7 13.5
BBS Elise (sector 111) Forged 17x8 17.8
BBS GTII Forged/Spun 18x10 21.2
BBS GTII Forged/Spun 18x11 22.9
BBS GTII Forged/Spun 18x8 20.3
BBS GTII Forged/Spun 18x8.5 20.7
BBS GTII Forged/Spun 18x9 21.0
BBS GTII Forged/Spun 18x9.5 21.8
BBS LM Forged/Spun 17x7 19.1
BBS LM Forged/Spun 17x7.5 18.9
BBS LM Forged/Spun 17x8 20.2
BBS LM Forged/Spun 17x9 20.5
BBS LM Forged/Spun 18x10 21.1
BBS LM Forged/Spun 18x10.5 22.7
BBS LM Forged/Spun 18x11 26.9
BBS LM Forged/Spun 18x13 29.4
BBS LM Forged/Spun 18x7.5 20.5
BBS LM Forged/Spun 18x8 21.1
BBS LM Forged/Spun 18x8.5 21.6
BBS LM Forged/Spun 18x9 22.4
BBS LM Forged/Spun 18x9.5 23.3
BBS LM Forged/Spun 19x10 25.1
BBS LM Forged/Spun 19x8.5 24.0
BBS LM Forged/Spun 19x9 24.2
BBS LM Forged/Spun 19x9.5 24.6
BBS LM Forged/Spun 20x10 26.2
BBS LM Forged/Spun 20x8.5 25.7
BBS LM Forged/Spun 20x9.5 26.6
BBS Primadonna Forged/Spun 17x8 20.0
BBS Primadonna Forged/Spun 18x10 22.7
BBS Primadonna Forged/Spun 18x8 22.4
BBS Primadonna Forged/Spun 18x9 22.9
BBS Primadonna Forged/Spun 19x8.5 23.3
BBS Primadonna Forged/Spun 19x9.5 24.0
BBS RC Cast (soft) 16x7 15.0
BBS RC Cast (soft) 16x7.5 16.0
BBS RC Cast (soft) 17x7 16.0
BBS RC Cast (soft) 17x8 16.4
BBS RC Cast (soft) 17x9 18.4
BBS RC Cast (soft) 18x10 19.5
BBS RC Cast (soft) 18x8 19.5
BBS RC Cast (soft) 18x8.5 18.7
BBS RCJ Forged 18x8 17.9
BBS RCJ Forged 18x9 18.7
BBS RD Cast 17x7 20.3
BBS RE Forged 18x10 21.8
BBS RE Forged 18x7.5 18.7
BBS RE Forged 18x8 20.2
BBS RE Forged 18x8.5 20.5
BBS RE Forged 18x9 20.9
BBS RE Forged 18x9.5 21.3
BBS RE Forged 20x10.5 24.9
BBS RE Forged 20x8.5 23.1
BBS RE Forged 20x9.5 23.3
BBS RE-Mg Forged Mg 18x10 16.5
BBS RE-Mg Forged Mg 18x11 18.5
BBS RE-Mg Forged Mg 18x8.5 15.4
BBS RE-Mg Forged Mg 18x9.5 16.7
BBS RG F1-Racing (Japan Only) Forged 15x6.5 9.9
BBS RG F1-Racing (Japan Only) Forged 15x7 10.2
BBS RG F1-Racing (Japan Only) Forged 16x7 12.6
BBS RG II Forged 18x8 20.2
BBS RG II Forged 18x9 21.3
BBS RG II / Open Forged 15x6.5 11.4
BBS RG II / Open Forged 16x7 12.8
BBS RG-F Forged 15x5.5 9.0
BBS RG-F Forged 15x6 9.2
BBS RG-F Forged 15x6.5 9.9
BBS RG-F Forged 15x7 10.2
BBS RG-F Forged 16x7 12.8
BBS RG-R Forged 17x7 16.5
BBS RG-R Forged 17x7.5 17.0
BBS RG-R Forged 17x8 16.9
BBS RG-R Forged 17x8.5 17.8
BBS RG-R Forged 17x9 17.2
BBS RG-R Forged 17x9.5 17.8
BBS RG-R Forged 18x10 19.8
BBS RG-R Forged 18x7.5 17.8
BBS RG-R Forged 18x8 18.0
BBS RG-R Forged 18x8.5 18.3
BBS RG-R Forged 18x9 18.9
BBS RG-R Forged 18x9.5 19.4
BBS RG-R Forged 19x10 21.8
BBS RG-R Forged 19x8.5 20.5
BBS RG-R Forged 19x9 20.7
BBS RG-R Forged 19x9.5 20.9
BBS RK Cast 15x7 14.2
BBS RK Cast 16x7 15.3
BBS RK Cast 16x8 15.9
BBS RK Cast 17x7 16.2
BBS RK Cast 17x8 16.5
BBS RK Cast 18x7.5 18.2
BBS RKII Cast 17x7.5 20.7
BBS RKII Cast 17x8 21.5
BBS RKII Cast 17x9 22.1
BBS RKII Cast 18x10 24.6
BBS RKII Cast 18x8.5 23.0
BBS RMII Cast/Spun 17x8 24.0
BBS RR Forged/Spun 17x7.5 18.7
BBS RR Forged/Spun 17x8 20.2
BBS RR Forged/Spun 17x9 20.7
BBS RR Forged/Spun 18x10 24.9
BBS RR Forged/Spun 18x7.5 21.3
BBS RR Forged/Spun 18x8 22.1
BBS RR Forged/Spun 18x8.5 23.1
BBS RR Forged/Spun 18x9.5 23.3
BBS RS Forged/Spun 16x7 16.0
BBS RS-GT Forged 17x7 17.5
BBS RS-GT Forged 17x7.5 18.3
BBS RS-GT Forged 17x8 18.7
BBS RS-GT Forged 17x8.5 18.9
BBS RS-GT Forged 17x9 19.8
BBS RS-GT Forged 18x10 22.0
BBS RS-GT Forged 18x11 24.4
BBS RS-GT Forged 18x8 19.1
BBS RS-GT Forged 18x8.5 20.0
BBS RS-GT Forged 18x9 20.2
BBS RS-GT Forged 18x9.5 21.1
BBS RS-GT Forged 19x10 22.9
BBS RS-GT Forged 19x8.5 21.8
BBS RS-GT Forged 19x9 22.4
BBS RS-GT Forged 19x9.5 22.0
BBS RS-GT Forged 20x8.5 22.7
BBS RS-GT Forged 20x9.5 22.9
BBS RSII Forged/Cast 17x8 23.0
BBS RSII Forged/Cast 18x10 25.4
BBS RSII Forged/Cast 18x8.5 24.0
BBS RSII Forged/Cast 20x10 28.3
BBS RSII Forged/Cast 20x9 27.4
BBS RTII Delta Cast/Spun 17x9.5 29.2
BBS RTII Delta Cast/Spun 18x10 33.4
BBS RV Cast 14x6 12.7
BBS RV Cast 15x7 15.5
BBS RV Cast 16x7 16.0
BBS RV Cast 16x8 18.2
BBS RV Cast 17x7.5 18.4
BBS RV Cast 17x8 21.1
BBS RV-F Forged 17x7 14.7
BBS RV-F Forged 17x7.5 15.4
BBS RWII Cast/Spun 17x7.5 22.6
BBS RWII Cast/Spun 17x8 23.9
BBS RWII Cast/Spun 18x10 26.3
BBS RWII Cast/Spun 18x8.5 25.3
BBS RX Cast 14x6 12.5
BBS RX Cast 15x7 14.7
BBS RX Cast 16x7 20.1
BBS RX Cast 16x8 22.0
BBS RX Cast 17x7.5 20.9
BBS RX Cast 17x8 23.3
BBS RX Cast 18x8 23.5
BBS RX Cast 18x8.5 25.1
BBS RXII Cast/Spun 14x5.5 13.3
BBS RXII Cast/Spun 14x6 13.9
BBS RXII Cast/Spun 17x7.5 21.2
BBS RXII Cast/Spun 17x8 23.6
BBS RXII Cast/Spun 18x8.5 26.3
BBS RZ Cast 17x7 21.8
BBS Super-RS Forged/Spun 17x8 20.0
BBS Super-RS Forged/Spun 18x10 22.7
BBS Super-RS Forged/Spun 18x8 22.4
BBS Super-RS Forged/Spun 18x9 22.6
BBS Super-RS Forged/Spun 19x8.5 23.3
BBS Super-RS Forged/Spun 19x9.5 24.0
BBS SX Cast 18x8 25.0
BBS VZ Cast 17x7.5 19.0
Billet Specialties E1 Cast 17x7 23.3
Billet Specialties SLX 21 Cast 18x7 22.4
Billet Specialties SLX 30 Cast 18x7 26.2
Black Racing Phantom Cast 15x6.5 14.3
Blitz Technospeed Z1 Forged/Spun 18x10 25.8
Blitz Technospeed Z1 Forged/Spun 19x10 28.5
Blitz Technospeed Z1 Forged/Spun 19x9 25.8
Blitz Technospeed Z2 Forged/Spun 18x9 24.0
Blitz Type 01R Forged 16x7 16.8
Blitz Type 02 Forged/Spun 15x7 13.0
Blitz Type 03 Forged/Spun 18x8 22.5
Blitz Type 03 Forged/Spun 18x9 26.8
BMW 320i Cast 13x6 10.8
BMW 328is Cast 16x7 19.0
BMW E30 M3 Cast 15x7 16.0
BMW E30 M3 (BBS RS003) Cast/Spun 16x7 16.0
BMW E34 M5 "Throwing Stars" Forged 17x8 19.5
BMW E36 M3 Contour Cast 17x7.5 22.3
BMW E36 M3 Contour Cast 17x8.5 23.4
BMW E36 M3 Doublespoke I (Motorsport) Cast 17x7.5 21.3
BMW E36 M3 Doublespoke I (Motorsport) Cast 17x8.5 22.3
BMW E36 M3 Doublespoke II Cast 17x7.5 20.7
BMW E36 M3 Doublespoke II Cast 17x8.5 21.9
BMW E36 M3 Forged Forged 17x7.5 19.7
BMW E36 M3 Forged Forged 17x8.5 20.9
BMW E36 M3 LTW Forged 17x7.5 19.5
BMW E36 M3 LTW Forged 17x8.5 20.7
BMW E39 M5 Forged 18x8 23.6
BMW E39 M5 Forged 18x9.5 25.6
BMW E46 M135 Cast 18x8 28.5
BMW E46 M135 Cast 18x8.5 29.0
BMW E46 M3 Compeition Cast 19x8 24.0
BMW E46 M3 Compeition Cast 19x9.5 25.5
BMW E46 Style 44 Cast 17x8 23.1
BMW E46 Style 68 Cast 17x7.5 21.0
BMW E46 Style 71 Forged/Spun 18x8 21.0
BMW E46 Style 71 Forged/Spun 18x8.5 22.0
BMW E90 Style 162 Cast 18x8 24.7
BMW E90 Style 162 Cast 18x8.5 26.2
BMW Parallels Forged 18x8 23.0
Bogart 13x5.5 15.3
Borbet Type B Cast 15x6.5 16.5
Borbet Type B Cast 15x7 17.5
Borbet Type B Cast 16x7.5 19.0
Borbet Type C Cast 15x7 16.5
Borbet Type C Cast 17x7.5 24.0
Borbet Type C2T Cast 17x7.5 28.0
Borbet Type C2T Cast 17x9 30.0
Borbet Type C2T (Porsche OE) Cast 17x7.5 22.0
Borbet Type C2T (Porsche OE) Cast 17x9 23.5
Borbet Type E Cast 15x7 17.5
Borbet Type E Cast 17x7 21.0
Borbet Type E Cast 17x8 23.6
Borbet Type F Cast 16x7 19.0
Borbet Type H Cast 15x7 18.5
Borbet Type M Cast 16x7 23.0
Borbet Type M Cast 17x8 27.5
Borbet Type R Cast 17x8 20.5
Borbet Type R Cast 18x8 23.0
Borbet Type S Cast 15x7 15.5
Borbet Type S Cast 17x7 21.0
Borbet Type S Cast 18x8 22.5
Borbet Type T Cast 14x6 14.2
Borbet Type T Cast 15x7 17.5
Borbet Type T Cast 16x7.5 21.0
Borbet Type T Cast 17x7 22.5
Borbet Type TD Cast 18x8 25.0
Borbet Type VS Cast 18x8 24.0
Branzach BZ-11 Cast 18x8 28.0
Branzach BZ-12 (Zeo) Cast 18x7.5 24.2
Breyton Inspiration Cast 17x7 23.5
Breyton Magic Cast 18x7 26.0
Breyton Magic Cast 18x8.5 28.0
Breyton Softline Cast 17x8 24.0
Bridgestone Super R.A.P. Cast 14x6 10.0
Brock B13 Cast 17x7.5 20.3
BSA 248 Cast 18x7.5 23.2
BSA 259 Cast 18x7.5 24.4
BSA Octopus Cast 16x7 19.5
Buddy Club P1 QF Forged 15x7 10.1
Buddy Club P1 QF Forged 16x7 11.1
Buddy Club P1 QF Forged 17x7.5 12.9
Buddy Club P1 QF Forged 17x8 13.6
Buddy Club P1 QF Forged 17x9 14.5
Buddy Club P1 QF Forged 17x9.5 15.1
Buddy Club P1 QF Forged 18x10 16.1
Buddy Club P1 QF Forged 18x9 14.8
Buddy Club PL Racing SF Cast 15x6.5 10.1
Buddy Club PL Racing SF Cast 17x7 17.0
Budnik Gasses Cast 17x8 20.0
Budnik Grid Cast 17x7 21.5
Budnik GT-5 Lite Cast 18x7 23.0
Budnik Pentacle FL Cast 17x8 25.2
Budnik Prism Cast 18x8 21.0
CAM 1 (Challenge) Cast 16x7 18.0
CAM 1 (Challenge) Cast 17x7 21.0
CAM 2 (Trophy) Cast 16x7 16.5
Carlsson Design 1/5 Cast 18x8.5 29.3
Carlsson Design 1/6 EVO Cast 19x8.5 33.3
Carlsson Design 2/5 Cast 18x8.5 33.0
Carusi Type 62 Cast 17x7 28.0
CCW (not hub or lug-centric) Forged/Spun 17x10 18.6
CCW (not hub or lug-centric) Forged/Spun 17x9.5 18.0
CCW (not hub or lug-centric) Forged/Spun 18x10 22.0
CEC Techart Daytona Cast 18x11 27.8
CEC Type 139 Cast 17x7 25.0
CEC Type 149 Cast 18x8 25.0
CEC Type 169 Cast 18x8.5 33.0
CEC Type 185 (Antera) Cast 17x7.5 27.0
CEC Type 971 (Valbrem) Cast 16x7 23.0
CEC Type 992 Cast 17x7.5 21.0
CEC Type H (Azev) Cast 17x7.5 26.0
Centerline Convo-Pro Forged 15x15 14.5
Centerline Impulse Forged 17x7 11.8
Centerline RPM Forged 17x7 13.5
Centerline RPM Forged 18x8.5 15.0
Centerline RPM Forged 19x7.5 15.6
Centerline Thruster 806 Cast 17x9.5 22.0
Chaparral S 15 Cast 15x7 15.3
Chevrolet Corvette Z06 01 Forged 17x9.5 19.6
Chevrolet Corvette Z06 01 Forged 18x10.5 21.4
Chevrolet Corvette Z06 01 - CCW skeletal mod Forged 17x9.5 17.8
Chevrolet Corvette Z06 01 - CCW skeletal mod Forged 18x10.5 19.8
Chevrolet Corvette Z06 02 Cast/Spun 17x9.5 19.2
Chevrolet Corvette Z06 02 Cast/Spun 18x10.5 21.0
Circlar GTA Cast 18x8.5 21.6
Circle Racing Series 82 Spun 13x5.5 7.7
Circle Racing Series 82 Spun 13x6 8.0
Circle Racing Series 82 Spun 13x7 8.7
Circle Racing Series 82 Spun 13x8 9.7
Circle Racing Series 82 Spun 14x7 11.5
Circle Racing Series 82 Spun 15x10 15.3
Circle Racing Series 82 Spun 15x7 12.2
Circle Racing Series 82 Spun 15x8 13.7
Circle Racing Series 82 Spun 16x7 13.2
Circle Racing Series 82 Spun 16x8 14.4
Circle Racing Series 82 Spun 16x9.5 15.8
Circle Racing Series 84 Spun 13x5.5 8.2
Circle Racing Series 84 Spun 13x6 8.8
Circle Racing Series 84 Spun 13x8 9.2
Club Linea Special Cast 18x8 25.0
Cobb Tuning CT-One Cast 17x7.5 22.0
Compomotive ML Cast 13x10 15.4
Compomotive ML Cast 13x5.5 13.2
Compomotive ML Cast 13x6 13.6
Compomotive ML Cast 13x7 14.3
Compomotive ML Cast 13x8 14.5
Compomotive ML Cast 13x9 14.7
Compomotive ML Cast 14x6 13.6
Compomotive ML Cast 15x5.5 16.5
Compomotive ML Cast 15x6 18.0
Compomotive ML Cast 15x7 20.9
Compomotive ML Cast 15x8 22.0
Compomotive MO Cast 14x5.5 15.0
Compomotive MO Cast 14x6 15.0
Compomotive MO Cast 15x6 17.2
Compomotive MO Cast 15x7 18.7
Compomotive MO Cast 15x8 18.9
Compomotive MO Cast 16x5.5 16.5
Compomotive MO Cast 16x6 16.9
Compomotive MO Cast 16x6.5 17.4
Compomotive MO Cast 16x7 19.6
Compomotive MO Cast 16x7.5 21.8
Compomotive MO Cast 16x8 20.9
Compomotive MO Cast 17x7 21.3
Compomotive MO Cast 17x7.5 22.4
Compomotive MO Cast 17x8 24.0
Compomotive MO Cast 18x8 26.4
Compomotive PS Cast 17x10 20.5
Compomotive TH Cast 13x5 11.2
Compomotive TH Cast 13x5.5 11.4
Compomotive TH Cast 14x5 12.8
Compomotive TH Cast 14x5.5 15.0
Compomotive TH Cast 14x6 15.6
Compomotive TH Cast 15x5 16.1
Compomotive TH Cast 15x5.5 16.3
Compomotive TH Cast 15x6 16.6
Compomotive TH Cast 15x6.5 17.8
Compomotive TH Cast 15x7 18.3
Compomotive TH Cast 15x7.5 19.1
Compomotive TH Cast 15x8 20.0
Compomotive TH Cast 16x5.5 20.0
Compomotive TH Cast 16x6 20.5
Compomotive TH Cast 16x7 20.9
Compomotive TH Cast 16x7.5 20.5
Compomotive TH Cast 16x8 20.9
Compomotive TH2 Cast 15x5.5 18.1
Compomotive TH2 Cast 15x6 16.9
Compomotive TH2 Cast 15x6.5 17.9
Compomotive TH2 Cast 15x7 18.1
Compomotive TH2 Cast 16x6.5 18.1
Compomotive TH2 Cast 17x7.5 21.2
Compomotive TH2 Cast 18x8 24.1
Concept Neeper Dagg Cast 20x8.5 33.0
Concept Neeper Fly Cast 20x8.5 32.0
Concept Neeper Haaz Cast 18x8.5 30.3
Concept Neeper N170 Cast 20x8.5 30.3
Concept Neeper Sideburn Cast 18x7 35.6
Concord Racing Cast 15x7 24.0
Cromodora Ego Cast 16x7 22.0
Cromodora Mg Cast Mg 13x5.5 8.8
Datsun 200SX 80-83 (16-spoke) Cast 14x5.5 15.0
Datsun 200SX 80-83 (32-spoke) Cast 14x5.5 16.0
Datsun 200SX 80-83 (disk) Cast 14x5.5 14.0
Datsun 280Z 79-80 Cast 14x6 18.0
Datsun 280ZX 81-83 Cast 14x6 13.0
Datsun 280ZX Turbo 81 Cast 15x6 17.0
Datsun 280ZX Turbo 82-83 Cast 15x6 14.0
Datsun 810/Maxima 81-84 Cast 14x5.5 15.0
DAZZ Camus Cast 19x9.5 27.3
DAZZ Matrix Cast 19x9.5 28.0
Desmond Rega Master EVO Forged 15x6.5 8.6
Desmond Rega Master EVO Forged 16x7 11.9
Desmond Rega Master EVO Forged 16x8 12.9
Desmond Rega Master EVO Forged 17x7 15.0
Detata DT-105 Cast 17x8 26.0
Detata DT-109 Cast 17x7.5 28.3
Detata DT-111 Cast 17x7.5 24.0
Diamond Racing Spun Steel 13x6 11.0
Diamond Racing Spun Steel 13x8 13.6
Diamond Racing Spun Steel 15x7 18.8
Dinan BMW (Fiske) Forged/Spun 18x9 18.0
Dodge Challenger 78-83 Cast 14x5.5 15.0
Dodge Colt 88-90 Cast 14x5.5 13.0
Dodge Conquest 84-85 (large vents) Cast 15x6.5 14.0
Dodge Conquest 84-86 Cast 14x6 15.0
Dodge Conquest 84-87 (all others) Cast 15x6.5 16.0
Dodge Neon ACR 02 Cast 15x6 16.5
Dodge Viper - 01 Cast 18x10 28.4
Dodge Viper - 01 Cast 18x13 32.3
DPE GT7 Forged 18x8 19.0
DPE R05 Variant S Forged 19x8 24.0
Drive Mach 5 Cast 20x8.5 34.3
Drive Zila Cast 20x8.5 42.5
Dronell CA-05 Cast 20x8.5 30.6
Dronell D-06 Cast 19x8 27.8
Dronell M-10 Forged 19x8.5 18.5
Dronell TS-05 Cast 17x7 18.0
Dronell TS-06 Cast 17x7 20.8
Dronell Type II Cast 19x7.5 28.8
DTM FS-01 Cast 15x6.5 14.8
DTM FS-02 Cast 15x6.5 14.7
DTM FS-02 Cast 17x7 21.0
Ducatro Daytona Cast/Spun 15x6.5 14.8
Duralight Cast 17x10 18.0
Dymag Callaway Corvette Cast Mg 17x8 12.9
Dymag Carbon Fibre Cast Mg/Carbon Fibre 18x10.5 15.9
Dymag Motorsport Cast Mg 15x6 10.8
Dymag Motorsport Cast Mg 16x7 13.0
Elite 726 Rockport Cast 16x7 20.0
Elite Barb Cast 18x7 28.4
Elite Indis Cast 20x8.5 36.5
EMO 502 (Ozone) Cast 15x7 22.0
EMO 702 (Obelix) Cast 15x7 20.6
EMPI 5-spoke Cast 15x5.5 20.0
Enkei 5+ Cast 17x7 19.0
Enkei Aegis Cast 17x7 20.7
Enkei Aegis Cast 17x8 21.9
Enkei Aegis Cast 17x9 22.1
Enkei Aegis Cast 18x10 24.3
Enkei Aegis Cast 18x8 23.1
Enkei Aegis Cast 18x8.5 23.3
Enkei Aegis Cast 18x9.5 23.7
Enkei Aegis Cast 19x8.5 24.8
Enkei Aegis Cast 19x9.5 24.9
Enkei Aka Cast 17x7.5 28.2
Enkei Aka Cast 18x7.5 30.0
Enkei Aka Cast 20x8.5 37.4
Enkei Arashi Cast 17x7 19.0
Enkei Bortex MII (RPM-2) Cast 17x7 16.0
Enkei Bortex MII (RPM-2) Cast 17x8 16.2
Enkei Bortex MII (RPM-2) Cast 17x9 17.9
Enkei Bortex MII (RPM-2) Cast 18x7.5 17.5
Enkei Bortex MII (RPM-2) Cast 18x8 17.5
Enkei Bortex MII (RPM-2) Cast 18x9 18.0
Enkei C.R.A.N.K. Cast 17x7.5 27.1
Enkei CDR9 Cast 15x6.5 16.7
Enkei CDR9 Cast 16x7 18.9
Enkei CDR9 Cast 17x7 21.6
Enkei CDR9 Cast 18x7 23.1
Enkei CTM-3 Cast 15x10 28.3
Enkei CTM-3 Cast 15x8 24.6
Enkei CTM-3 Cast 16x8 27.1
Enkei CTM-4 Cast 16x8 28.4
Enkei CTM-5 Cast 15x10 25.0
Enkei CTM-5 Cast 15x8 24.0
Enkei CTM-5 Cast 16x8 24.5
Enkei Duji Cast 17x7 23.0
Enkei ERO-1 Cast 15x7 17.2
Enkei ERO-1 Cast 16x7 18.0
Enkei ES-Gravel Cast 14x6 12.9
Enkei ES-Tarmac Cast 14x6 8.7
Enkei ES-Tarmac Cast 14x6.5 8.9
Enkei ES-Tarmac Cast 15x6.5 10.7
Enkei ES-Tarmac Cast 15x7 11.0
Enkei ES-Tarmac Cast 15x7.5 11.6
Enkei ES-Tarmac Cast 16x7 13.7
Enkei ES-Tarmac Cast 16x7.5 14.3
Enkei ES-Tarmac Cast 17x7.5 14.8
Enkei Etoria Cast 15x6 17.0
Enkei EUM5 Cast 15x6.5 16.0
Enkei EUM5 Cast 16x7 18.0
Enkei Exocent Cast 19x9.5 31.0
Enkei Fubuki Cast 17x7 23.2
Enkei Gattling Cast 18x10 27.0
Enkei GTV Cast 18x8 24.3
Enkei Inazuma Cast 17x7 21.7
Enkei J-Speed III Cast/Spun 14x5 11.0
Enkei J-Speed III Cast/Spun 14x6 11.2
Enkei J-Speed III Cast/Spun 14x6.5 11.5
Enkei J-Speed III Cast/Spun 14x7 11.7
Enkei J-Speed III Cast/Spun 15x6 12.6
Enkei J-Speed III Cast/Spun 15x6.5 12.8
Enkei J-Speed III Cast/Spun 15x7 13.2
Enkei J-Speed III Cast/Spun 15x7.5 13.4
Enkei J-Speed III Cast/Spun 16x7 15.0
Enkei J-Speed III Cast/Spun 16x7.5 15.4
Enkei J-Speed III Cast/Spun 16x8 16.1
Enkei Kriminal Cast 23x10 60.0
Enkei Liberty Cast 17x9 32.8
Enkei Liberty Cast 18x9 33.6
Enkei NP03 Cast 16x7 17.6
Enkei NP03 Cast 18x7 19.3
Enkei NT03 M Cast 17x7.5 17.4
Enkei NT03 M Cast 17x8 18.9
Enkei NT03 M Cast 17x9.5 20.0
Enkei NT03 M Cast 18x10 20.5
Enkei NT03 M Cast 18x10.5 21.0
Enkei NT03 M Cast 18x7.5 18.5
Enkei NT03 M Cast 18x8 19.4
Enkei NT03 M Cast 18x8.5 19.6
Enkei NT03 M Cast 18x9.5 19.9
Enkei Phalenx Cast 17x7 21.9
Enkei Phalenx Cast 17x8 23.0
Enkei Phalenx Cast 17x9 23.3
Enkei Phalenx Cast 18x10 26.2
Enkei Phalenx Cast 18x7 23.1
Enkei Phalenx Cast 18x8 23.8
Enkei Phalenx Cast 18x9 24.2
Enkei Phalenx Cast 19x10 29.6
Enkei Phalenx Cast 19x8.5 28.5
Enkei RC5 Cast 17x7 18.0
Enkei RC5 Cast 18x9 19.5
Enkei RCT-1 Cast 15x7 14.5
Enkei RCT-1 Cast 16x7 16.7
Enkei RCT-1 Cast 17x7 17.8
Enkei RF1 Cast 16x7 16.5
Enkei RF-1 Cast 15x7 15.9
Enkei RF-1 Cast 16x7 16.5
Enkei RF-1 Cast 17x7 18.1
Enkei RMR Cast 17x7.5 20.0
Enkei RP-F1 Cast 19x8.5 19.9
Enkei RP-F1 Cast 15x7 9.8
Enkei RP-F1 Cast 16x7 13.4
Enkei RP-F1 Cast 17x7 15.0
Enkei RP-F1 Cast 17x7.5 15.3
Enkei RP-F1 Cast 17x8 15.6
Enkei RP-F1 Cast 17x9 16.0
Enkei RP-F1 Cast 17x9.5 16.5
Enkei RP-F1 Cast 18x7.5 17.0
Enkei RP-F1 Cast 18x8 17.8
Enkei RP-F1 Cast 18x8.5 18.3
Enkei RP-F1 Cast 18x9.5 17.2
Enkei RP-F1 Cast 19x10 20.7
Enkei RP-F1 Cast 19x8 18.7
Enkei RP-F1 Cast 19x9.5 19.6
Enkei RP-F1 RC Cast/Spun 18x8.5 22.0
Enkei RPM-2 Cast 17x7 16.9
Enkei RPM-2 Cast 17x8 17.4
Enkei RPM-2 Cast 17x9 18.7
Enkei RPM-2 Cast 18x7.5 18.9
Enkei RPM-2 Cast 18x8 19.4
Enkei RPM-2 Cast 18x9 21.1
Enkei RPO-1 Cast 15x7 14.3
Enkei RPO-1 Cast 16x6.5 14.5
Enkei RPO-1 Cast 16x7 15.8
Enkei RPO-1 Cast 17x7 17.6
Enkei RPO-1 Cast 17x7.5 18.0
Enkei RPO-1 Cast 17x8 18.2
Enkei RPO-1 Cast 17x9 20.0
Enkei RPO-1 Cast 18x8.5 20.7
Enkei RPO-1 Cast 18x9 21.3
Enkei RPO-1 Cast 18x9.5 23.4
Enkei RPO-2 Cast 15x5 14.1
Enkei RPO-2 Cast 15x7 15.2
Enkei RPO-2 Cast 16x7 17.0
Enkei RPO-2 Cast 16x8 17.5
Enkei RPO-2 Cast 17x7 18.5
Enkei RPO-2 Cast 17x7.5 19.1
Enkei RPO-2 Cast 17x8 19.8
Enkei RPO-2 Cast 17x9 20.3
Enkei RPO-2 Cast 18x7.5 20.8
Enkei RPO-2 Cast 18x8 21.3
Enkei RPO-2 Cast 18x9 21.9
Enkei RPO-2J Cast 15x7 13.0
Enkei RPO-3 Cast 17x10 21.4
Enkei RPO-3 Cast 17x7 16.8
Enkei RPO-3 Cast 17x8 17.9
Enkei RPO-3 Cast 17x8.5 19.1
Enkei RPO-3 Cast 17x9.5 19.6
Enkei RPO-3 Cast 18x10 21.5
Enkei RPO-3 Cast 18x7.5 19.2
Enkei RPO-3 Cast 18x8 20.2
Enkei RPO-3 Cast 18x8.5 20.9
Enkei RPO-3 Cast 18x9 21.0
Enkei RPO-3 Cast 18x9.5 21.3
Enkei RPO-3 Cast 19x10 23.1
Enkei RPO-3 Cast 19x8 20.5
Enkei RPO-3 Cast 19x8.5 20.6
Enkei RPO-3 Cast 19x9 21.8
Enkei RPO-3 Cast 19x9.5 22.2
Enkei RPO-5 Cast 17x7 20.0
Enkei RPO-5 Cast 18x7 22.0
Enkei RPO-7 Cast 18x7 20.0
Enkei RPO-7 Cast 19x7.5 21.0
Enkei RPOM Cast 17x7 19.5
Enkei RPOM Cast 18x7 21.0
Enkei RS Evolution Cast 16x7 17.0
Enkei RS Evolution Cast 17x7 19.4
Enkei RS+M Cast 15x5 11.7
Enkei RS+M Cast 15x6.5 14.0
Enkei RS+M Cast 15x7 14.8
Enkei RS+M Cast 16x7 14.8
Enkei RS+M Cast 17x7 15.7
Enkei RS+M Cast 18x7.5 17.8
Enkei RS+M Cast 18x8.5 19.3
Enkei RS-5 Cast 15x6.5 15.4
Enkei RS-5 Cast 16x7 17.6
Enkei RS-5 Cast 17x7 19.8
Enkei RS-5 Cast 18x7 21.6
Enkei RS-6 Cast 15x6.5 17.5
Enkei RS-6 Cast 16x7 19.6
Enkei RS-6 Cast 17x7 20.2
Enkei RS-6 Cast 18x7 23.3
Enkei RS-E Cast 16x7 18.1
Enkei RS-E Cast 17x7 19.4
Enkei RSF-2 Cast 15x6.5 16.3
Enkei RSF-2 Cast 16x7 18.1
Enkei RSF-2 Cast 17x7 19.8
Enkei RSF-2 Cast 18x7 21.8
Enkei RT6 Cast 17x8 24.6
Enkei RT6 Cast 18x8.5 26.1
Enkei RTO-1 Cast 16x7 16.0
Enkei RTS Cast 16x8 22.1
Enkei RTS Cast 17x8 23.9
Enkei Shogun Cast 17x7 24.9
Enkei Shutoko Cast 17x7 23.7
Enkei Silverstar Cast 17x9 29.7
Enkei Silverstar Cast 18x9 30.6
Enkei SS6A Cast 15x6.5 15.8
Enkei Suzuka Cast 17x7 21.5
Enkei Tatonka Cast 17x8 28.5
Enkei Tatonka Cast 18x9 30.3
Enkei TBS1 Cast 16x7 18.3
Enkei TBS1 Cast 17x7 20.0
Enkei TBS11 Cast 16x7 18.3
Enkei TBS11 Cast 17x7 20.0
Enkei Tuscarora Cast 16x8 26.7
Enkei Tuscarora Cast 17x8 28.4
Enkei Tuscarora Cast 18x9 32.5
Enkei V-1 Cast 17x8 23.8
Enkei V-1 Cast 17x8.5 23.9
Enkei V-1 Cast 17x9 24.2
Enkei V-1 Cast 17x9.5 25.0
Enkei V-1 Cast 18x10 27.4
Enkei V-1 Cast 18x8 26.0
Enkei V-1 Cast 18x8.5 26.6
Enkei V-1 Cast 18x9 26.7
Enkei V-1 Cast 18x9.5 27.0
Enkei Valor Cast 17x9 30.0
Enkei Valor Cast 18x9 30.3
Enkei Valor Cast 20x9 33.8
Enkei Victory Cast 17x9 30.0
Enkei Victory Cast 18x9 31.2
Enkei Victory Cast 20x9 33.9
Enkei Zenkei Cast 17x7 26.0
Enkei Zoku Cast 17x7 19.8
Enkei ZXC Cast 17x8.5 21.4
Enkei ZXC Cast 18x9 23.8
Enzo Cup Cast 17x8 28.8
Enzo M Cast 16x7.5 23.5
Enzo V Cast 16x7 22.0
Epic Laguna Cast 16x7.5 24.5
Epic Series 73 (Aero) Cast 17x7 26.0
Esses SpeedMaster SM-058 Cast 15x7 15.4
Falken Atlantic City Cast 20x8.5 33.2
Falken Atlantic City Cast 22x9 35.6
Falken Atlantic City Cast 23x10 40.0
Falken Circuit Spec Cast 17x7 22.5
Falken Circuit Spec Cast 18x7 26.5
Falken Circuit Spec Cast 19x7.5 26.0
Falken Circuit Spec Cast 19x8 27.5
Falken Explicit Cast 17x7.5 17.0
Falken Explicit Cast 18x7.5 19.0
Falken Explicit Cast 20x8.5 30.5
Falken Hanabi Cast 15x7 11.5
Falken Hanabi Cast 17x7.5 17.0
Falken Hanabi Cast 18x7.5 19.0
Falken Hanabi Cast 18x8.5 20.0
Falken Koblenz Cast 18x8 25.1
Falken Koblenz Cast 18x9 26.6
Falken Koblenz Cast 19x10.5 32.5
Falken Koblenz Cast 19x8.5 25.8
Falken Koblenz Cast 19x9.5 31.7
Falken Koblenz Cast 20x8.5 33.3
Falken Roid Cast 20x8.5 31.3
Falken Roid Cast 22x9.5 34.5
Falken Roid Cast 23x10 37.5
Falken Spine Cast 20x8.5 28.8
Falken Spine Cast 22x9.5 36.0
Falken Spine Cast 23x10 37.7
Falken Torque 5 Cast 17x7 24.0
Falken Torque 5 Cast 18x7 25.0
Falken Torque 5 Cast 18x8 26.8
Falken Torque 5 Cast 19x7.5 26.5
Falken Torque 5 Cast 19x8 28.5
Fast Wheels 13x5.5 14.0
Fikse ARO Forged/Spun 17x10 18.9
Fikse FM-10 Forged/Spun 17x10 18.5
Fikse FM-10 Forged/Spun 18x8 20.8
Fikse FM-10 Forged/Spun 18x9.5 20.9
Fikse FM-5 Forged/Spun 17x10 18.5
Fikse FM-5 Forged/Spun 17x8 16.0
Fikse FM-5 Forged/Spun 17x8.5 17.5
Fikse FM-5 Forged/Spun 18x8.5 18.0
Fikse Mach 5 Forged/Spun 17x10 18.5
Final Speed Forged Forged 17x7.5 13.0
Fittipaldi 500 SS Cast 17x7 23.3
Fittipaldi 916 SP Cast 18x8 23.3
Fittipaldi Argus Cast 20x8.5 31.0
Fittipaldi AV3 Cast 17x8 27.0
Fittipaldi Avus Cast 17x8 27.0
Fittipaldi Fin Cast 18x8.5 29.4
Fittipaldi Flame Cast 17x7 20.0
Fittipaldi Polaris Cast 17x8 28.5
Fittipaldi Tubolare Cast 18x8 33.0
Fittipaldi Vela Cast 18x8 23.3
Flik Apex Cast 15x6.5 11.9
Flik Apex Cast 16x7 15.0
Flik Apex2 Cast 16x7 14.8
Flik Artic Cast 17x7 18.0
Flik Artic Cast 18x8.5 23.0
Flik Blast Cast 15x6.5 11.9
Flik Bullet Cast 15x6.5 12.5
Flik Bullet Cast 17x7 17.0
Flik Fuel Cast 15x6.5 12.0
Flik Fuel Cast 17x7 17.0
Flik Justice Cast 17x8 22.0
Flik Justice Cast 18x8 25.0
Flik Justice Cast 19x8 27.0
Flik Lex Cast 17x7 18.0
Flik Lex Cast 17x8 19.0
Flik Lex Cast 18x8 22.0
Flik Titan Cast 17x7 18.0
Flik Wasp Cast 17x7 19.0
Flik Wasp Cast 18x7.5 22.0
Focal F1 (Type 173) Cast 18x7 25.6
Focal F10 Cast 18x7 26.3
Focal F5 Cast 17x7 23.5
Focal F5 Cast 18x7 25.0
Focal G7 Cast 18x7 27.3
Focal R3 Cast 18x7 26.3
Focal SD5 Cast 18x7 26.0
Fondmetal Tech 4 Cast 18x8 27.8
Fondmetal Type 6500 Cast 17x7 24.0
Fondmetal Type 6700 Cast 16x7 22.2
Fondmetal Type 6800 Cast 16x7 22.6
Fondmetal Type 9a Cast 17x7 24.6
Ford Focus ZTS and Wagon Cast 15x6 15.2
Ford Focus ZX3 Cast 16x6 19.1
Ford Mustang - Roush (made by Prime) Cast 17x8 26.5
Ford Taurus SHO Cast 16x6.5 18.8
Forgeline LS Forged/Spun 17x8 19.5
Forgeline LS Forged/Spun 17x9.5 18.5
Forgeline RS Forged/Spun (brittle) 16x8 17.2
Forgeline RS Forged/Spun (brittle) 17x9.5 18.5
Forgeline RS Forged/Spun (brittle) 18x9.5 22.5
Formula F1 (TE-37 copy) Cast 15x6.5 13.5
Formula F1 (TE-37 copy) Cast 16x7 15.5
Formula F1 (TE-37 copy) Cast 17x7 18.5
Formula F1 (TE-37 copy) Cast 18x7 19.5
GAB Sports Cast 16x7 15.0
GAB Sports Cast 16x8 16.3
Gianelle 5 (Twin) Cast 18x7.5 24.2
Gianelle 6 (Oval) Cast 18x8.5 27.2
Giovanna Akita Cast 18x7.5 20.0
Giovanna Anzio Cast 18x7.5 22.8
Giovanna Anzio Cast 22x9.5 37.0
Giovanna Barletta Cast 20x8.5 46.0
Giovanna Berlin Cast 20x10 42.0
Giovanna Boizano Cast 20x8.5 37.0
Giovanna Chiba Cast 18x7.5 24.5
Giovanna Kobe Cast 18x7.5 24.3
Giovanna Kuji Cast 18x7.5 26.3
Giovanna Kyoto Cast 18x7.5 25.0
Giovanna Mito Cast 18x7.5 22.6
Giovanna Nagano Cast 18x7.5 23.0
Giovanna Rio Cast 18x8.5 29.5
Giovanna Suzu Cast 15x6.5 12.5
GMC Syclone/Typhoon (Front) Cast/Spun 16x8 21.2
GMC Syclone/Typhoon (Rear) Cast/Spun 16x8 21.8
Gram Lights 57C Cast 15x7 13.5
Gram Lights 57C Cast 16x7 15.4
Gram Lights 57C Cast 17x7.5 18.0
Gram Lights 57F Forged 18x8.5 20.0
Gram Lights 57Pro Cast 17x7 19.5
Gram Lights 57S Cast 16x7 16.0
Gram Lights 57S Cast 17x7.5 17.5
Hamann Magnesium Forged 19x8.5 18.0
Hart Sport Diablo Cast 17x10 21.0
Hart Sport Mirage Cast 17x10 21.0
Hart Sport Odyssey Cast 17x10 21.0
Hartge Classic Cast 19x8 24.0
Hartge Classic Cast 19x9 26.0
Hartge Classic Cast 19x9.5 30.0
Hartge Nova 3 Cast 18x8.5 25.0
Hartge Nova 5 Cast 19x9.5 31.0
Hayashi Street Wheel Cast 15x6.5 13.2
Hayashi Street Wheel Cast 15x7 13.9
Hickock Sprint Forged 18x11 18.0
Hickock Sprint Forged 18x9.5 17.0
Hokuto Racing Miyabi Cast 17x7 21.5
Honda Accord Type R (Euro) Cast 17x7 21.8
Honda Civic 88-91 Stamped Steel 13x5 16.0
Honda Civic EX/Si 92+ Cast 14x5 18.0
Honda Civic HX 96-97 Cast 14x5.5 11.8
Honda Civic Si 02-04 Cast 15x6 22.2
Honda Civic Si 05+ HFP Cast 17x7 20.0
Honda Civic Si 99-00 Cast 15x6 18.0
Honda Civic Type R 02 Cast 17x7 20.2
Honda Civic VX Cast 13x5 9.7
Honda CRX Si 86-87 Cast 14x5 15.4
Honda CRX Si 90 Cast 14x5 16.0
Honda Prelude 97-99 Cast 16x6.5 19.0
Honda Prelude 97-99 SH Cast 16x6.5 19.7
Honda Prelude VTEC 93 Cast 15x6.5 22.5
Honda Prelude VTEC/Si 95-96 Cast 15x6.5 17.0
Honda S2000 Cast 16x6.5 17.5
Honda S2000 Cast 16x7.5 18.6
Honda S2000 04+ Cast 17x7 17.6
Honda S2000 04+ Cast 17x8.5 20.5
Honda S2000 JDM (BBS) Forged 16x6.5 13.3
Honda S2000 JDM (BBS) Forged 16x7.5 14.3
HP Racing Avalanche Cast 17x7.5 23.0
HP Racing Flight Cast 18x8 22.0
HP Racing Fusion Cast 17x7 21.2
HP Racing Hurricane Cast 17x7 18.5
HP Racing Lightning Cast 17x7 19.8
HP Racing Shadow Cast 18x8 25.0
HP Racing Vortex Cast 18x7.5 25.8
HRE 445 Forged/Spun 18x10 20.4
HRE 447 Forged/Spun 18x10 25.3
HRE 504 Forged/Spun 17x11 19.5
HRE 504 Forged/Spun 17x9.5 18.0
HRE 504 Forged/Spun 18x7.5 16.5
HRE 535 Forged/Spun 17x10 22.0
HRE 540 Forged/Spun 17x10 24.0
HRE 540 Forged/Spun 17x8.5 23.0
HRE 540 Forged/Spun 18x10 26.0
HRE 545 Forged/Spun 17x10 25.0
HRE 545 Forged/Spun 18x10 27.0
HRE 546 Forged/Spun 18x8.5 20.0
HRE 546 Forged/Spun 20x9 27.0
HRE 547 Forged/Spun 17x10 23.0
HRE 547 Forged/Spun 18x10 23.0
HRE 835 Forged/Spun 17x10 18.0
IFG A5 Forged 17x8 18.5
IFG A5 Forged 17x9 20.0
iForged Aero Forged 19x10 25.0
iForged Aero Forged 19x10.5 26.0
iForged Aero Forged 19x11 27.0
iForged Aero Forged 19x7.5 22.0
iForged Aero Forged 19x8 22.0
iForged Aero Forged 19x8.5 23.0
iForged Aero Forged 19x9 24.0
iForged Aero Forged 19x9.5 24.0
iForged Aero Forged 20x10 27.0
iForged Aero Forged 20x8 25.0
iForged Aero Forged 20x8.5 25.0
iForged Aero Forged 20x9 26.0
iForged Aero Forged 22x10 35.0
iForged Aero Forged 22x9.5 30.0
iForged Evolution Forged 19x10 25.0
iForged Evolution Forged 19x10.5 26.0
iForged Evolution Forged 19x11 27.0
iForged Evolution Forged 19x7.5 22.0
iForged Evolution Forged 19x8 22.0
iForged Evolution Forged 19x8.5 23.0
iForged Evolution Forged 19x9 24.0
iForged Evolution Forged 19x9.5 24.0
iForged Evolution Forged 20x10 27.0
iForged Evolution Forged 20x8 25.0
iForged Evolution Forged 20x8.5 25.0
iForged Evolution Forged 20x9 26.0
iForged Evolution Forged 22x10 35.0
iForged Evolution Forged 22x9.5 30.0
iForged Flux Forged 19x10 25.0
iForged Flux Forged 19x10.5 26.0
iForged Flux Forged 19x11 27.0
iForged Flux Forged 19x7.5 22.0
iForged Flux Forged 19x8 22.0
iForged Flux Forged 19x8.5 23.0
iForged Flux Forged 19x9 24.0
iForged Flux Forged 19x9.5 24.0
iForged Flux Forged 20x10 27.0
iForged Flux Forged 20x8 25.0
iForged Flux Forged 20x8.5 25.0
iForged Flux Forged 20x9 26.0
iForged Flux Forged 22x10 35.0
iForged Flux Forged 22x9.5 30.0
iForged Marquis Forged 19x10 25.0
iForged Marquis Forged 19x10.5 26.0
iForged Marquis Forged 19x11 27.0
iForged Marquis Forged 19x7.5 22.0
iForged Marquis Forged 19x8 22.0
iForged Marquis Forged 19x8.5 23.0
iForged Marquis Forged 19x9 24.0
iForged Marquis Forged 19x9.5 24.0
iForged Marquis Forged 20x10 27.0
iForged Marquis Forged 20x8 25.0
iForged Marquis Forged 20x8.5 25.0
iForged Marquis Forged 20x9 26.0
iForged Marquis Forged 22x10 35.0
iForged Marquis Forged 22x9.5 30.0
iForged Retro Forged 19x10 25.0
iForged Retro Forged 19x10.5 26.0
iForged Retro Forged 19x11 27.0
iForged Retro Forged 19x7.5 22.0
iForged Retro Forged 19x8 22.0
iForged Retro Forged 19x8.5 23.0
iForged Retro Forged 19x9 24.0
iForged Retro Forged 19x9.5 24.0
iForged Retro Forged 20x10 27.0
iForged Retro Forged 20x8 25.0
iForged Retro Forged 20x8.5 25.0
iForged Retro Forged 20x9 26.0
iForged Retro Forged 22x10 35.0
iForged Retro Forged 22x9.5 30.0
iForged Rev Forged 19x10 25.0
iForged Rev Forged 19x10.5 26.0
iForged Rev Forged 19x11 27.0
iForged Rev Forged 19x7.5 22.0
iForged Rev Forged 19x8 22.0
iForged Rev Forged 19x8.5 23.0
iForged Rev Forged 19x9 24.0
iForged Rev Forged 19x9.5 24.0
iForged Rev Forged 20x10 27.0
iForged Rev Forged 20x8 25.0
iForged Rev Forged 20x8.5 25.0
iForged Rev Forged 20x9 26.0
iForged Rev Forged 22x10 35.0
iForged Rev Forged 22x9.5 30.0
iForged Seneka Forged 19x10 25.0
iForged Seneka Forged 19x10.5 26.0
iForged Seneka Forged 19x11 27.0
iForged Seneka Forged 19x7.5 22.0
iForged Seneka Forged 19x8 22.0
iForged Seneka Forged 19x8.5 23.0
iForged Seneka Forged 19x9 24.0
iForged Seneka Forged 19x9.5 24.0
iForged Seneka Forged 20x10 27.0
iForged Seneka Forged 20x8 25.0
iForged Seneka Forged 20x8.5 25.0
iForged Seneka Forged 20x9 26.0
iForged Seneka Forged 22x10 35.0
iForged Seneka Forged 22x9.5 30.0
iForged Sprint Forged 19x10 25.0
iForged Sprint Forged 19x10.5 26.0
iForged Sprint Forged 19x11 27.0
iForged Sprint Forged 19x7.5 22.0
iForged Sprint Forged 19x8 22.0
iForged Sprint Forged 19x8.5 23.0
iForged Sprint Forged 19x9 24.0
iForged Sprint Forged 19x9.5 24.0
iForged Sprint Forged 20x10 27.0
iForged Sprint Forged 20x8 25.0
iForged Sprint Forged 20x8.5 25.0
iForged Sprint Forged 20x9 26.0
iForged Sprint Forged 22x10 35.0
iForged Sprint Forged 22x9.5 30.0
iForged Swift Forged 19x10 25.0
iForged Swift Forged 19x10.5 26.0
iForged Swift Forged 19x11 27.0
iForged Swift Forged 19x7.5 22.0
iForged Swift Forged 19x8 22.0
iForged Swift Forged 19x8.5 23.0
iForged Swift Forged 19x9 24.0
iForged Swift Forged 19x9.5 24.0
iForged Swift Forged 20x10 27.0
iForged Swift Forged 20x8 25.0
iForged Swift Forged 20x8.5 25.0
iForged Swift Forged 20x9 26.0
iForged Swift Forged 22x10 35.0
iForged Swift Forged 22x9.5 30.0
iForged Technik Forged 19x10 25.0
iForged Technik Forged 19x10.5 26.0
iForged Technik Forged 19x11 27.0
iForged Technik Forged 19x7.5 22.0
iForged Technik Forged 19x8 22.0
iForged Technik Forged 19x8.5 23.0
iForged Technik Forged 19x9 24.0
iForged Technik Forged 19x9.5 24.0
iForged Technik Forged 20x10 27.0
iForged Technik Forged 20x8 25.0
iForged Technik Forged 20x8.5 25.0
iForged Technik Forged 20x9 26.0
iForged Technik Forged 22x10 35.0
iForged Technik Forged 22x9.5 30.0
Import Development Forged 19x10 21.0
Import Development Forged 19x8 19.5
Import Development Forged 19x8.5 20.0
Impul NS-01R Forged 17x7.5 14.5
Infinity G20 91-97 Cast 14x6 15.0
Infinity M30 90-92 Cast 15x6.5 17.0
InterMilano RG6 Cast 15x6.5 12.0
InterMilano RG6 Cast 16x7 16.5
Isuzu Impulse Stylus/Geo Storm 90-93 Stamped Steel 14x5.5 16.0
Isuzu Impulse Stylus/Geo Storm 90-93 Cast 14x5.5 14.0
Isuzu Impulse Stylus/Geo Storm 90-93 Cast 15x6 17.4
Jax Light Cast 15x6.5 12.9
Joustmeister Forged 17x7 13.0
J's Racing PR 6 Forged Mg 17x7.5 13.2
J's Racing PR 6 Forged Mg 17x8.5 13.6
Katana Belajeo Cast 18x7.5 26.0
Katana Berlini Cast 18x8 26.7
Katana Concept Six Cast 18x7.5 24.0
Katana Ducati Cast 18x7.5 25.0
Kazera KZ-A Cast 17x7.5 20.0
Kazera KZ-B Cast 17x7.5 22.0
Kazera KZ-B Cast 18x7.5 22.5
Kazera KZ-R Cast 16x7 17.6
Kazera KZ-R Cast 17x7 18.6
Kazera KZ-R Cast 18x7 19.4
Kazera KZ-S Cast 16x7 18.0
Kazera KZ-S Cast 17x7 19.0
Kazera KZ-S Cast 18x7 20.4
Kazera KZ-S Cast 19x7.5 24.0
Kazera KZ-T Cast 17x7.5 19.8
Kazera KZ-T Cast 18x7.5 21.2
Kazera KZ-U Cast 16x7 18.5
Kazera KZ-U Cast 17x7 19.5
Kazera KZ-U Cast 18x7 20.5
Kazera KZ-V Cast 16x7 16.5
Kazera KZ-V Cast 17x7 17.5
Kazera KZ-V Cast 18x7 19.0
Keizer (racing only) Cast 13x8 7.8
Kid's Racing Cast 14x6 9.7
Kid's Racing Cast 15x6.5 10.6
Kinesis K20 Forged/Spun 17x10 20.0
Kinesis K20 Forged/Spun 17x9 19.5
Kinesis K28 Forged/Spun 18x8.5 21.5
Kinesis K28 Forged/Spun 18x9.5 22.5
Kinesis K5 Forged/Spun 17x10 18.0
Kinesis K5 Forged/Spun 17x8.5 17.0
Kinesis K58 Forged/Spun 18x10 24.0
Kinesis K58 Forged/Spun 18x8 23.0
Kinesis Supercup Forged/Spun 17x10 22.0
KMC Alf Cast 17x7 26.0
KMC Gear Cast 17x7 24.5
KMC Street Rebel Spyder Cast 17x7 21.0
KMC Suicide 320 Cast 18x7 20.6
KMC Tarantula Cast 17x7 23.5
KMC Wizdom Cast 18x7 24.0
KMS Superlight Forged 15x7 10.1
KMS Superlight Forged 16x8 11.9
Konig Absolute Cast 17x7 21.2
Konig Absolute Cast 18x7.5 22.8
Konig Antarres Cast 13x6 15.5
Konig Antarres Cast 16x7.5 21.0
Konig Appeal Cast 17x7 18.2
Konig Appeal Cast 17x8 20.4
Konig Appeal Cast 17x9.5 22.2
Konig Appeal Cast 18x8 22.2
Konig Appeal Cast 19x8.5 23.8
Konig Appeal Cast 20x8.5 26.3
Konig Arrive Cast 20x8.5 36.3
Konig Blatant Cast 18x8 22.6
Konig Burner Cast 15x7 16.0
Konig Burner Cast 16x7 17.2
Konig Caffeine Cast 15x6.5 16.5
Konig Caffeine Cast 16x7 19.0
Konig Caffeine Cast 17x7 19.9
Konig Caffeine Cast 17x8 20.1
Konig Caffeine Cast 18x7.5 21.9
Konig Coastal Cast 20x8.5 35.2
Konig Coastal Cast 20x9.5 37.4
Konig Coastal Cast 22x9.5 38.7
Konig Cobra Cast 15x6.5 16.0
Konig Cobra Cast 16x7 19.5
Konig Cobra Cast 17x7.5 22.0
Konig Competition Cast 16x7 18.4
Konig Diva Cast 13x5.5 12.5
Konig Diva Cast 14x6 13.2
Konig Diva Cast 15x6.5 15.8
Konig Diva Cast 17x7.5 19.5
Konig Diva Cast 18x7.5 22.0
Konig Drift Cast 17x7 20.2
Konig Drift Cast 18x8 22.0
Konig DTM Cast 17x7.5 21.0
Konig Elan Cast 16x7 18.0
Konig Elan Cast 17x7 20.0
Konig Elan Cast 18x8 21.0
Konig Five-O Cast 16x8 19.2
Konig Five-O Cast 17x8 20.1
Konig Flatline Cast 15x6.5 17.9
Konig Flatline Cast 16x7 19.8
Konig Flatline Cast 17x7 21.1
Konig Flatline Cast 18x7.5 22.6
Konig Flight Cast 15x6.5 17.4
Konig Flight Cast 16x7 18.4
Konig Flight Cast 17x8 20.1
Konig Flight Cast 17x9.5 27.3
Konig Flight Cast 18x7.5 23.5
Konig Flight Cast 18x8 24.9
Konig Freefall Cast 16x7 18.3
Konig Freefall Cast 17x7 20.9
Konig Freefall Cast 18x7.5 22.2
Konig Glide Cast 17x7 22.6
Konig Greenlight Cast 15x6.5 15.4
Konig GT-R Cast 15x6.5 16.0
Konig GT-R Cast 16x7 17.5
Konig GT-R Cast 17x7 19.5
Konig Helium Cast 15x6.5 11.5
Konig Helium Cast 16x7 16.4
Konig Holes Cast 15x6.5 13.8
Konig Holes Cast 16x7 16.1
Konig Holes Cast 17x7 17.8
Konig Holes Cast 18x7.5 21.3
Konig Holes Cast 19x7.5 21.8
Konig Holes Cast 19x8 21.4
Konig Hurry Cast 15x6.5 13.6
Konig Imagine Cast 17x7 22.4
Konig Imagine Cast 18x7.5 25.3
Konig Imagine Cast 18x8.5 28.4
Konig Imagine Cast 19x8 27.5
Konig Impact Cast 17x7.5 21.0
Konig Kilo Cast 15x6.5 11.5
Konig Kolors Cast 15x7 15.0
Konig Kolors Cast 17x7 17.4
Konig LiveWire Cast 17x7 24.9
Konig LiveWire Cast 18x7.5 26.2
Konig Monsoon Cast 15x6.5 16.4
Konig Monsoon Cast 16x7 19.5
Konig Monsoon Cast 17x7 21.0
Konig Monsoon Cast 17x8 22.6
Konig Monsoon Cast 17x9.5 24.0
Konig Monsoon Cast 18x7.5 26.0
Konig MP3 Cast 17x7.5 23.4
Konig MP3 Cast 18x7.5 24.9
Konig Network Cast 15x7 13.4
Konig Next Cast 15x7 14.0
Konig Next Cast 17x7 18.7
Konig Next Cast 18x7.5 20.7
Konig Next Cast 19x8 23.3
Konig Next Cast 19x9 25.1
Konig Nrn Cast 16x8 18.4
Konig Nrn Cast 17x8 21.0
Konig Octane Cast 16x7 19.1
Konig OpenRoad Cast 20x8.5 35.2
Konig OpenRoad Cast 20x9.5 35.2
Konig OpenRoad Cast 22x9.5 37.0
Konig Prophet Cast 17x7.5 22.5
Konig Prophet Cast 18x7.5 22.7
Konig Prophet Cast 18x8 24.3
Konig Prophet Cast 19x8 24.5
Konig Prowler Cast 16x7 24.0
Konig Rated-R Cast 14x6 14.5
Konig Rated-R Cast 15x6.5 16.5
Konig Rated-R Cast 16x7 17.5
Konig Rated-R Cast 17x7 19.2
Konig Rated-R Cast 18x7.5 21.5
Konig Rewind Cast 15x7 14.6
Konig Rhythym Cast 17x7 20.9
Konig Rhythym Cast 18x7.5 22.5
Konig Rush Cast 14x6 13.5
Konig Rush Cast 15x6.5 17.7
Konig Rush Cast 16x7 19.0
Konig Rush Cast 17x7.5 22.8
Konig Rush Cast 18x7.5 24.9
Konig Rush Cast 19x8 26.5
Konig Septor Cast 17x7 21.2
Konig Spec Cast 17x7 21.2
Konig SubZero Cast 15x6.5 12.9
Konig SubZero Cast 17x7.5 16.9
Konig Tantrum Cast 15x6.5 16.5
Konig Tantrum Cast 16x7 17.9
Konig Tantrum Cast 17x7 19.2
Konig Tantrum Cast 17x8 22.9
Konig Tantrum Cast 17x9 23.0
Konig Tantrum Cast 18x7.5 23.2
Konig Tantrum Cast 18x8 24.9
Konig Tantrum Cast 18x9 25.3
Konig Tantrum Cast 19x8 27.0
Konig Tantrum 2 Cast/Spun 18x10 23.4
Konig Temperr Cast 17x7.5 20.7
Konig Temperr Cast 18x7.5 22.9
Konig Tequila Cast 17x7 19.0
Konig Theory Cast 17x7 19.3
Konig Theory Cast 18x7.5 20.3
Konig Theory Cast 18x8 22.4
Konig Theory Cast 19x8 24.5
Konig Toxxin Cast 17x7.5 18.6
Konig Toxxin Cast 18x7.5 19.8
Konig Traffik Cast 18x7.5 20.5
Konig Tremor Cast 17x8.5 23.2
Konig Tremor Cast 20x8.5 28.2
Konig Trouble Cast 15x6.5 16.5
Konig Trouble Cast 16x7 18.7
Konig Trouble Cast 17x7 19.8
Konig Trouble Cast 18x7.5 23.1
Konig Trouble Cast 18x8 24.2
Konig Trouble Cast 19x8 26.4
Konig Trouble Cast 19x9 28.6
Konig Tuner Cast 15x6.5 17.0
Konig Tuner Cast 16x7 17.5
Konig Tuner Cast 17x7 18.0
Konig Tuner2 Cast 17x7.5 21.6
Konig Tuner2 Cast 18x7.5 27.0
Konig Tuner2 Cast 19x7.5 26.4
Konig Tuner2 Cast 20x7.5 27.1
Konig Unkn
__________________
i will not tiptoe through life to arrive at death safely!Spider Monkey Celica GT-SImage hosted by Photobucket.com
milesplume is offline   View this Members' Photo Gallery Reply With Quote
Old 03-24-2006, 08:14 PM   #45
Shizuma
Professional Carsmith

Join Date: Mar 2005
Location: Houston, TX
Posts: 6,311
iTrader: (42)
Send a message via AIM to Shizuma
^ holy crap man...good wurk (:
__________________
Shizuma is offline   View this Members' Photo Gallery Reply With Quote
Old 03-24-2006, 09:03 PM   #46
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
Quote:
Originally Posted by elcelicagts
this is all good info.... BUT what about someone getting all these numbers and picking the more pratical stock items to remove-
ADD them up, SUBTRACT the total weigth of the lightest aftermarket parts (replacing some of the stock parts removed). SUBTRACT that total with the stock Gts celicas normal weight to get = the cars new capable weight.

from what i see i bet we can shave off at least 200 pounds without going a lil over board with the weight reduction. back seats and spare tires alone remove around 100 pounds total weight loss to the cars weight. just plain cool.

Sounds to me like you just volunteered yourself for this chore
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-24-2006, 09:06 PM   #47
Boosted2.0

Join Date: Oct 2003
Location: Houston, TX
Posts: 15,564
iTrader: (19)
Blog Entries: 1
Good Lord Miles!!!!

Where did that data come from?
__________________
Talk to us for all your performance needs!
We specialize in Motor builds, tuning, custom fabrication, high end / high HP engines, intake manifolds, exhaust manifolds, suspension, custom wiring, custom turbos, tuning, etc. We can get any part you want, usually for less than you would expect!

WWW.DDPerformanceResearch.com
Boosted2.0 is offline   View this Members' Photo Gallery Reply With Quote
Old 03-25-2006, 04:11 AM   #48
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
^^ From a wheel weights page, I have a couple of those pages in my "favorites", including the one he posted. Not all of them are made in the Celica bolt pattern or in acceptable offsets, though, which is why I didn't post them. Anyway, instead of posting all of that information, it would probably be better just to link to the site? (your call).

I like how he said he himself put them in alphabetical order

Anyway, here are a couple of wheel weights pages:

www.wheelweights.net/ (you can choose by alphabetical order, by size, or by weight)

www.wheelweights.com (manufacturer specs...but I'd say at least half of the weight specs aren't filled in).


There are also a couple of other pages that link off of the first stie. If Miles really wants to take credit for something, he can do research to find out which rims come in the Celica bolt pattern & acceptable offsets.
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Old 03-25-2006, 10:26 AM   #49
Monster Hui

Join Date: Jan 2003
Location: Victoria BC Canada
Posts: 257
iTrader: (3)
Send a message via ICQ to Monster Hui
the problem with both of those sites is that it's not stated which numbers are manulfacturer or which are actually weighted... and we all know how manulfacturers cheat on these numbers

they are good for referencing, but can't trust them 100%

i think we should have the links stickied, but have actual items that we have weighted on there
__________________
Celica Garage
REVscene.net

Monster Hui is offline   Reply With Quote
Old 03-25-2006, 06:09 PM   #50
Speed4TheNeed

Join Date: Jul 2004
Location: New Orleans, LA
Posts: 4,471
iTrader: (20)
Send a message via AIM to Speed4TheNeed
^^ I'll agree to that. Although I still think it's worth mentioning that users scales MAY not be 100% accurate as well. And most reputable wheel manufacturers will list pretty accurate weights.

I just think it's better to link to the sites than list them all...solely because of quantity.
__________________
Engine: MWR Stroker kit [Crower rods, Wiseco 12.5:1 pistons, Darton dry sleeves, Toyota 1zz crank], Piper stage II camshafts, Supertech valves, Eibach valve springs, Circuitworx O/P gear, Moroso oil pan, TRD RACE header, AEM CAI, TRD Kazuma exhaust, MWR main & rod bearing sets, ES motor mount inserts, Hondata IMG, UR crank, water pump, and alternator pullies, APEX'i PFC, TRD thermostat, Koyo Racing radiator, Blitz radiator hose, ARP 2ZZ complete stud set
Speed4TheNeed is offline   View this Members' Photo Gallery Reply With Quote
Reply

Bookmarks

Thread Tools
Display Modes

Go Back   NewCelica.org Forum > Celica Discussion > Performance Mods

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off

Forum Jump


All times are GMT -7. The time now is 07:09 PM.

vBulletin Security provided by vBSecurity v2.2.2 (Pro) - vBulletin Mods & Addons Copyright © 2019 DragonByte Technologies Ltd.
